Запчасти Komatsu PC1600-1 ЦИЛИНДР КОВША(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC1600-1 - ЦИЛИНДР КОВША(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
5
5
5
5
6
6
6
6
7
8
9
10
11
12
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
26
26
27
28
29
30
31
32
33
34
34
35
35
36
36
37
38
39
40
41
42
43
44
45
46
47
48
49
49
50
51
52
52
53
53
54
54
55
55
56
56

Артикул

Название

Примечание

Количество

G-1

707-01-XZ620

CYLINDER GROUP,L.H. (FINAL COATING)

G-1

21T-63-X2170

CYLINDER GROUP,L.H.

G-2

707-01-XZ630

CYLINDER GROUP,R.H. (FINAL COATING)

G-2

21T-63-X2180

CYLINDER GROUP,R.H.

|1

21T-63-02170

CYLINDER ASS'Y

1

21T-63-72540

CYLINDER

2

21T-63-72520

ROD,PISTON

3

707-46-14010

BUSHING

4

21T-72-15850

BUSHING

5

21T-72-15860

BUSHING

6

21T-72-15870

SEAL (KIT)

7

07179-14160

RING,SNAP

8

198-63-93170

SEAL,DUST (KIT)

9

707-28-20560

HEAD,CYLINDER

10

707-51-14130

PACKING,ROD (KIT)

11

707-35-92050

RING,BACK-UP (KIT)

12

07000-15195

O-RING (KIT)

13

07001-05195

RING,BACK-UP (KIT)

14

707-51-14630

RING (KIT)

15

707-52-91150

BUSHING

16

01010-52795

BOLT

17

01643-32780

WASHER

18

707-71-31460

COLLAR

19

707-71-11450

RING

20

707-71-51480

PLUNGER

21

07000-12115

O-RING (KIT)

22

707-35-52860

RING,BACK-UP (KIT)

23

707-36-20410

PISTON

24

707-37-20020

PISTON

25

707-44-20180

RING,PISTON (KIT)

26

707-39-20820

RING,WEAR (KIT)

27

707-40-20960

SPACER

28

01252-31490

BOLT

29

07043-00108

PLUG

30

21T-63-72570

TUBE,L.H.

|30

21T-63-72670

TUBE,R.H.

31

21T-62-88230

TUBE,L.H.

|31

21T-62-88250

TUBE,R.H.

32

707-88-87361

BRACKET

|32

707-88-87360

BRACKET

33

707-88-87370

BRACKET

34

707-88-96110

BAND

35

01010-51240

BOLT

36

01643-31232

WASHER

37

07000-13038

O-RING (KIT)

38

01010-51280

BOLT

39

01643-31232

WASHER

40

07000-13048

O-RING (KIT)

41

01010-51450

BOLT

42

01643-31445

WASHER

43

176-61-41330

CLAMP

44

01010-51250

BOLT

45

01643-31232

WASHER

46

707-88-88480

PLATE

47

01010-51225

BOLT

48

01643-31232

WASHER

49

07283-24346

CLIP

50

01599-01011

NUT

51

01643-31032

WASHER

52

07000-13048

O-RING,(FOR SHIPPING)

53

07378-11410

HEAD,(FOR SHIPPING)

54

07371-51470

FLANGE,(FOR SHIPPING)

55

01010-51455

BOLT,(FOR SHIPPING)

56

01643-31445

WASHER,(FOR SHIPPING)

|K

707-99-77330

SERVICE KIT

Выбрано товаров: 65
