Запчасти Komatsu PC1600-1 ОСНОВН. НАСОС (7/8) (NO. НАСОС) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-25-03011

PUMP ASS'Y

|1

708-25-03010

PUMP ASS'Y

|1

708-25-08241

SERVO VALVE ASS'Y,REAR

|1

708-23-07011

BODY ASS'Y

1

BODY

2

EXPANDER

3

708-25-15120

PISTON

4

708-25-15270

ARM

5

708-25-15130

SEAT

6

708-25-55120

SPRING

7

708-25-55130

SPRING

8

708-23-15120

SEAT

9

708-23-15160

PLUG

10

07000-02018

O-RING

11

708-25-15150

COVER

12

01580-10806

NUT

13

708-25-15320

BOLT

14

01602-20619

WASHER,SPRING

15

708-25-15171

PLUG

16

07002-02034

O-RING

17

07239-12009

NUT

18

07040-11007

PLUG

19

07002-01023

O-RING

20

708-25-15180

SLEEVE

21

708-25-15280

SPOOL

22

708-25-15310

SPRING

23

708-25-15330

SPACER

24

708-25-15430

PLUG

25

708-25-15340

SCREW

26

07000-02012

O-RING

27

708-25-15250

COVER

28

01580-10806

NUT

29

708-25-15320

BOLT

30

01602-20619

WASHER,SPRING

31

708-25-15260

PLUG

32

07002-00823

O-RING

33

04205-00514

PIN

34

04050-01210

PIN,COTTER

35

708-25-55110

PLATE

36

720-68-11920

FILTER

37

07000-12010

O-RING

38

07000-02011

O-RING

39

01010-80825

BOLT

40

01602-20825

WASHER,SPRING

41

708-25-19150

ORIFICE

42

720-68-11920

FILTER

43

07000-12010

O-RING

44

07000-11009

O-RING

45

07000-03048

O-RING

46

708-25-15460

SHIM¤ 0.05MM

|46

708-25-15470

SHIM¤ 0.10MM
