Запчасти Komatsu PC1600-1 КОРПУС КОНЕЧН. ПЕРЕДАЧИ И ЗВЕЗДОЧКА (/) НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|1

21T-27-00103

FINAL DRIVE ASS'Y,L.H.

|1

21T-27-00102

FINAL DRIVE ASS'Y,L.H.

|1

21T-27-00101

FINAL DRIVE ASS'Y,L.H.

|1

21T-27-00100

FINAL DRIVE ASS'Y,L.H.

|1

21T-27-00113

FINAL DRIVE ASS'Y,R.H.

|1

21T-27-00112

FINAL DRIVE ASS'Y,R.H.

|1

21T-27-00111

FINAL DRIVE ASS'Y,R.H.

|1

21T-27-00110

FINAL DRIVE ASS'Y,R.H.

1

21T-27-71240

SHAFT

2

21T-27-71230

SPACER

3

06044-00221

BEARING

4

21T-27-71210

GEAR

5

21T-27-71220

HOLDER

6

01010-81650

BOLT

|6

01010-51650

BOLT

7

21T-27-71270

CARRIER

8

21T-27-71250

GEAR

9

21T-27-71380

BEARING

10

21T-27-71430

PIN

11

209-27-51450

LOCK

12

01010-81230

BOLT

|12

01010-51230

BOLT

13

01643-31232

WASHER

14

21T-27-71260

GEAR

15

21T-27-71130

CASE

16

21T-27-11540

WASHER,THRUST

17

04020-00616

PIN

18

07044-13620

PLUG

19

07002-13634

O-RING

|19

07002-03634

O-RING

20

07049-02025

PLUG

21

209-27-51470

NIPPLE

22

01643-31032

WASHER

23

06044-00209

BEARING,ROLLER

24

21T-27-71190

SHAFT

25

01011-82015

BOLT

|25

01011-52015

BOLT

26

01643-32060

WASHER

27

21T-27-71110

CASE,L.H.

|27

21T-27-71120

CASE,R.H.

28

04020-01638

PIN

29

07049-01620

PLUG

30

01010-81655

BOLT

|30

01010-51655

BOLT

31

01643-31645

WASHER

32

209-27-51180

COUPLING
