Запчасти Komatsu PC1600-1 СИСТЕМА ТРУБ РАДИАТОРА (/) СИСТЕМА ОХЛАЖДЕНИЯ

1

209-03-51231

TUBE

|1

209-03-51230

TUBE

2

6210-61-6441

GASKET

|2

6210-61-6440

GASKET

3

01010-81035

BOLT

|3

01010-51035

BOLT

4

01643-31032

WASHER

5

209-03-51261

HOSE

|5

209-03-51260

HOSE

6

07289-00070

CLAMP

|6

208-09-11120

CLAMP

7

209-03-51241

TUBE

|7

209-03-51240

TUBE

8

195-03-18651

GASKET

|8

195-03-18650

GASKET

9

01010-81235

BOLT

|9

01010-51235

BOLT

10

01643-31232

WASHER

11

21T-03-71440

TUBE

12

07285-00095

CLIP

13

08036-01414

CLIP

14

01010-81220

BOLT

|14

01010-51220

BOLT

15

01643-31232

WASHER

16

08034-00519

BAND

17

07260-20990

HOSE

18

07281-00197

CLAMP

19

07343-24808

GASKET

|19

07343-04808

GASKET

20

209-03-51310

ELBOW

21

01010-81260

BOLT

|21

01010-51260

BOLT

22

01643-31232

WASHER

23

07343-02708

GASKET

24

209-03-51320

TUBE

25

01010-81030

BOLT

|25

01010-81035

BOLT

26

01643-31032

WASHER

27

198-911-5120

HOSE

|27

195-03-18680

HOSE

28

07289-00045

CLAMP

|28

207-09-11110

CLAMP

29

195-03-11511

CLIP

30

01010-81225

BOLT

|30

01010-51225

BOLT

31

01643-31232

WASHER

32

08034-00834

BAND
