Запчасти Komatsu PC1600-1 ЦИЛИНДР КОВША(№-9) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC1600-1 - ЦИЛИНДР КОВША(№-9) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
5
5
5
5
6
6
6
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
26
27
27
28
29
30
31
32
33
34
34A
35
36
37
38
39
39
40
40
41
41
41
41
41
41
41
42
42
43
43
44
44
45
46
47
48
48
48
49
50
51
52
53
54
55
56
57
57
58
58
59
59
60
60
61
61

Артикул

Название

Примечание

Количество

G1

21T-63-X2050

CYLINDER GROUP,L.H.

G1

21T-63-X2060

CYLINDER GROUP,R.H.

|$3

21T-63-02050

CYLINDER ASS'Y

1

21T-63-72142

CYLINDER

2

21T-63-72121

ROD,PISTON

3

707-46-14010

BUSHING

4

21T-72-15850

BUSHING

5

21T-72-15860

BUSHING

6

21T-72-15870

SEAL (KIT)

7

707-75-14012

RING,SNAP

8

198-63-93170

SEAL,DUST (KIT)

9

707-28-20150

HEAD,CYLINDER

10

707-51-14130

PACKING,ROD (KIT)

11

07001-05200

RING,BACK-UP (KIT)

12

07000-15200

O-RING (KIT)

13

707-51-14630

RING,BUFFER (KIT)

14

707-52-91150

BUSHING

14

707-52-11410

BUSHING

15

01011-83025

BOLT

16

01643-33080

WASHER

17

01011-83005

BOLT

18

01643-33080

WASHER

19

707-71-73330

CAPILLARY

20

07042-20108

PLUG

21

07000-11009

O-RING (KIT)

22

07001-01009

RING,BACK-UP (KIT)

23

07002-11823

O-RING (KIT)

24

707-36-20931

PISTON

25

707-44-20180

RING,PISTON (KIT)

25

707-44-20080

RING,PISTON (KIT)

26

07155-02045

RING,WEAR (KIT)

27

707-39-20911

RING,WEAR (KIT)

28

19M-63-52271

NUT

29

07000-12095

O-RING (KIT)

30

07001-02095

RING,BACK-UP (KIT)

31

707-71-51520

PLUNGER

32

707-71-31531

COLLAR

33

707-71-31540

COLLAR

34

707-71-11510

RING

34A

07043-00108

PLUG

35

21T-63-72370

TUBE,L.H.

35

21T-63-72470

TUBE,R.H.

36

21T-63-72380

TUBE,L.H.

36

21T-63-72480

TUBE,R.H.

37

707-88-96650

BRACKET

38

707-88-96660

BRACKET

39

707-88-96640

BAND

40

01010-51240

BOLT

41

01643-31232

WASHER

42

01010-51450

BOLT

43

01643-31445

WASHER

44

07000-13048

O-RING (KIT)

45

176-61-41330

CLAMP

46

01010-51250

BOLT

47

707-88-10930

BRACKET

48

01010-51230

BOLT

49

01010-51235

BOLT

50

07283-24354

CLIP

51

01599-01011

NUT

52

01643-31032

WASHER

53

707-88-10940

BRACKET

54

209-63-52170

PLATE

55

01010-51020

BOLT

56

01602-21030

WASHER

57

07000-13048

O-RING,(FOR SHIPPING)

58

07378-11410

HEAD,(FOR SHIPPING)

59

07371-51470

FLANGE,(FOR SHIPPING)

60

01010-51455

BOLT,(FOR SHIPPING)

61

01643-31445

WASHER,(FOR SHIPPING)

|$71

707-99-77210

SERVICE KIT

Выбрано товаров: 70
