Запчасти Komatsu PC1600-1 ОСНОВН. НАСОС (/8) (NO. НАСОС) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
№
Артикул
Название
Примечание
Количество
|$2
708-25-03011
PUMP ASS'Y
|$3
708-25-03010
PUMP ASS'Y
|$7
708-25-04180
PUMP SUB ASS'Y
|$8
708-25-51201
PUMP SUB ASS'Y
|$9
708-25-00310
CASE ASS'Y,FRONT
1
CASE,FRONT
2
PLUG
3
07044-12412
PLUG
4
07002-02434
O-RING
|$14
708-25-00660
END CAP ASS'Y,FRONT
|$15
708-25-00340
END CAP ASS'Y,FRONT
5
CAP,FRONT
5
CAP,FRONT
6
PLUG
7
708-2E-12260
BEARING
7
708-25-12740
BEARING
8
07000-02135
O-RING
9
6130-21-1910
PIN,DOWEL
10
07000-12015
O-RING
11
07000-11009
O-RING
12
07000-03032
O-RING
13
708-25-12530
BOLT
14
04530-01018
BOLT,EYE
15
708-25-52710
SHAFT,FRONT
16
708-2L-22150
BEARING
17
708-25-05010
WASHER KIT
17
WASHER, 2.0MM
17
WASHER, 2.1MM
17
WASHER, 2.2MM
18
708-25-12790
RING,SNAP
19
708-25-05140
WASHER KIT
19
WASHER, 2.25MM
19
WASHER, 2.55MM
19
WASHER, 2.85MM
19
WASHER, 3.15MM
19
WASHER, 3.45MM,3.45MM
19
WASHER, 3.75MM,3.75MM
20
06000-51106
BEARING
21
708-25-52830
RING
22
708-25-52840
RETAINER
23
708-25-05021
SHIM KIT
23
SHIM, 0.5MM,0.50MM
23
SHIM, 0.2MM,0.20MM
23
SHIM, 0.15MM,0.15MM
23
SHIM, 0.1MM,0.10MM
24
708-25-12950
PLATE
25
706-74-40320
BOLT
26
01643-31032
WASHER
27
708-25-52860
SEAL,OIL
28
708-25-12812
HOUSING
28
708-25-12811
HOUSING
29
07000-02080
O-RING
30
708-25-05130
SHIM KIT
30
SHIM, 0.2MM
30
SHIM, 0.1MM
31
01010-80820
BOLT
31
01010-30820
BOLT
32
01643-30823
WASHER
