Запчасти Komatsu PC1600-1 КОВШ¤ 9.M (ДЛЯ НИЖН. РАЗГРУЗКА) (AGC СПЕЦ-Я.) (ДЛЯ ПОГРУЗ.)(№7-) РАБОЧЕЕ ОБОРУДОВАНИЕ

1

21T-961-3161

BUCKET,FRONT

2

21T-72-74141

ADAPTER (WELDED)

3

21T-961-3170

PLATE (WELDED)

4

209-939-5170

SHROUD (WELDED)

5

21T-961-3190

PLATE (WELDED)

5

21T-961-3180

PLATE,CENTER (WELDED)

6

21T-72-74280

BUSHING

7

21T-72-74290

SEAL

8

21T-72-74311

POINT

9

21T-72-74320

PIN ASS'Y

10

21T-961-3210

SHROUD

11

01011-83015

BOLT,REAR

12

01643-33080

WASHER,REAR

13

01580-13024

NUT,REAR

14

21T-961-3150

BUCKET,REAR

15

21T-72-74180

BUSHING

16

21T-72-74190

BUSHING

17

21T-72-74220

BUSHING

18

21T-72-74360

COVER

19

01010-81630

BOLT

20

01643-31645

WASHER

21

21T-72-74271

PIN

22

07020-00000

FITTING,GREASE

23

207-70-11230

PLATE

24

01010-81640

BOLT

24

01010-51640

BOLT

25

01643-31645

WASHER

26

21T-72-74260

PIN

27

709-63-21340

PLATE

28

01010-81235

BOLT

28

01010-51235

BOLT

29

01643-31232

WASHER

30

07049-01215

PLUG

31

21T-72-74240

PIN

32

07049-01620

PLUG

33

21T-72-74250

HOLDER

34

01010-81645

BOLT

34

01010-51645

BOLT

35

01643-31645

WASHER

36

21T-72-74171

PIN

37

21T-72-74210

HOLDER

38

01010-82460

BOLT

38

01010-52460

BOLT

39

01643-32460

WASHER

40

07049-02430

PLUG

41

07020-00000

FITTING,GREASE
