Запчасти Komatsu PC1600-1 МЕХ-М ОТБОРА МОЩНОСТИ (/)(№-9) КОМПОНЕНТЫ ДВИГАТЕЛЯ

|$2

21T-38-00075

POWER TAKE OFF ASS'Y

|$3

21T-38-00074

POWER TAKE OFF ASS'Y

|$4

21T-38-00073

POWER TAKE OFF ASS'Y

|$5

21T-38-00072

POWER TAKE OFF ASS'Y

|$6

21T-38-00071

POWER TAKE OFF ASS'Y

|$7

21T-38-00070

POWER TAKE OFF ASS'Y

1

21T-38-71113

CASE

1

21T-38-71112

CASE

1

21T-38-71111

CASE

2

04020-01638

PIN

3

209-38-11270

NIPPLE

4

209-38-51180

GEAR

5

209-38-51660

BEARING

5

06002-32024

BEARING

6

209-38-51170

SPACER

7

04065-01030

RING

8

209-38-51190

GEAR

9

06030-06313

BEARING

10

209-38-51210

GEAR

11

06030-06313

BEARING

11

209-38-51610

BEARING

11

06030-06213

BEARING

12

209-38-51221

GEAR

13

06030-06313

BEARING

13

209-38-51610

BEARING

13

06030-06213

BEARING

14

209-38-11291

PLUG

15

07005-03016

GASKET

16

07030-03034

BREATHER

17

07005-03016

GASKET

18

07049-03645

PLUG

19

209-38-51140

PLATE

20

01010-81245

BOLT

21

01643-31232

WASHER

22

209-38-51150

COUPLING

23

209-09-51120

BOLT

24

01643-31645

WASHER

25

209-38-51160

SHAFT

26

07000-35500

O-RING

27

01010-81245

BOLT

28

01643-31232

WASHER
