Запчасти Komatsu PC1600-1-A ЦИЛИНДР РУКОЯТИ(№7-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

21T-63-X2210

CYLINDER GROUP,R.H.

G-1

21T-63-X2220

CYLINDER GROUP,L.H.

|1

21T-63-02210

CYLINDER ASS'Y

1

21T-63-67340

CYLINDER

2

21T-63-67320

ROD,PISTON

3

21T-72-15850

BUSHING

4

707-46-14020

BUSHING

5

21T-72-15870

SEAL,DUST

6

707-75-16020

RING,SNAP

7

707-56-16110

SEAL,DUST

8

707-27-25160

HEAD,CYLINDER

9

707-52-91350

BUSHING

10

707-51-16130

PACKING,ROD

11

707-51-16630

RING,BAFFLE

12

07000-15250

O-RING

13

07001-05250

RING,BACK-UP

14

01011-83330

BOLT

15

01643-33380

WASHER

16

707-36-25050

PISTON

17

707-44-25180

RING,PISTON

18

707-36-25060

PISTON

19

707-39-25820

RING,WEAR

20

707-40-22960

SPACER

21

01253-31615

BOLT

22

07000-15135

O-RING

23

707-35-91440

RING,BACK-UP

24

707-71-50371

PLUNGER

25

04260-01270

BALL

26

707-71-91380

PIN

27

21T-63-67370

TUBE,L.H.

|27

21T-63-67470

TUBE,R.H.

28

21T-63-67380

TUBE

29

07000-13048

O-RING

30

01010-51450

BOLT

31

01643-31445

WASHER

32

707-88-11740

BRACKET

33

07283-24354

CLIP

34

01599-01011

NUT

35

01643-31032

WASHER

36

01010-51245

BOLT

37

01643-31232

WASHER

38

707-88-11730

CLAMP

39

01010-51250

BOLT

40

01643-31232

WASHER

41

707-88-96700

BRACKET

42

707-88-87340

BRACKET

43

707-99-96710

BAND

44

01010-51240

BOLT

45

01643-31232

WASHER

46

07000-12060

O-RING

47

01011-51645

BOLT

48

01643-31645

WASHER

49

07000-13048

O-RING,(FOR SHIPPING)

50

07378-11410

HEAD,(FOR SHIPPING)

51

07371-51470

FLANGE,(FOR SHIPPING)

52

01010-51455

BOLT,(FOR SHIPPING)

53

01643-31445

WASHER,(FOR SHIPPING)
