Запчасти Komatsu PC1600-1-A ЦИЛИНДР СТРЕЛЫ(№7-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

21T-63-X2190

CYLINDER GROUP,L.H.

G-2

21T-63-X2200

CYLINDER GROUP,R.H.

|1

21T-63-02190

CYLINDER ASS'Y

1

21T-63-57340

CYLINDER

2

21T-63-57320

ROD

3

707-46-16010

BUSHING

4

707-46-16050

BUSHING

5

707-77-16010

SEAL

6

01253-33650

BOLT

7

707-41-10270

WASHER

8

707-75-19020

RING

9

707-56-19110

SEAL

10

707-28-28140

HEAD

11

707-51-19130

PACKING,ROD

12

07001-05280

RING

13

07000-15280

O-RING

14

707-51-19630

RING,BUFFER

15

707-52-91660

BUSHING

16

707-71-62050

PLUNGER

17

707-71-20510

RING

18

707-71-40520

COLLAR

19

07000-15165

O-RING

20

707-35-91750

RING,BACK-UP

|21

707-91-02830

PISTON SUB ASS'Y

21

707-37-28050

PISTON

22

195-63-12471

SEAT

23

707-83-10120

VALVE,PISTON

24

707-83-10110

VALVE,PISTON

25

707-80-12010

SPRING

26

707-44-28180

RING,PISTON

27

707-39-28820

RING,WEAR

28

707-37-28020

PISTON

29

707-40-28970

SPACER

30

01253-31815

BOLT

31

21T-63-57370

TUBE,L.H.

|31

21T-63-57470

TUBE,R.H.

32

21T-63-57380

TUBE,L.H.

|32

21T-63-57480

TUBE,R.H.

33

07000-13048

O-RING

34

01010-51450

BOLT

35

01643-31445

WASHER

36

707-88-96670

BRACKET

37

707-88-96680

BAND

38

01010-51250

BOLT

39

01643-31232

WASHER

40

707-88-11720

BRACKET

41

01010-51230

BOLT

42

01643-31232

WASHER

43

707-88-11730

CLAMP

44

01010-51290

BOLT

45

01643-31232

WASHER

46

07000-13048

O-RING,(FOR SHIPPING)

47

07378-11410

HEAD,(FOR SHIPPING)

48

07371-51470

FLANGE,(FOR SHIPPING)

49

01010-51455

BOLT,(FOR SHIPPING)

50

01643-31445

WASHER,(FOR SHIPPING)
