Запчасти Komatsu PC1600-1-A ОСНОВН. НАСОС (/8) (NO. НАСОС) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-25-03011

PUMP ASS'Y

|1

708-25-03010

PUMP ASS'Y

|1

708-25-04180

PUMP SUB ASS'Y

|1

708-25-51201

PUMP SUB ASS'Y

1

708-25-52721

SHAFT,REAR

2

708-2L-22150

BEARING

3

708-25-05010

WASHER KIT

|3

WASHER¤ 2.0MM

|3

WASHER¤ 2.1MM

|3

WASHER¤ 2.2MM

4

708-25-12790

RING,SNAP

5

06000-51106

BEARING

6

708-25-52830

RING

7

708-25-52840

RETAINER

8

708-25-05140

WASHER KIT

|8

WASHER¤ 2.25MM

|8

WASHER¤ 2.55MM

|8

WASHER¤ 2.85MM

|8

WASHER¤ 3.15MM

|8

WASHER¤ 3.45MM

|8

WASHER¤ 3.75MM

|9

708-25-00411

CYLINDER BLOCK ASS'Y,REAR

|9

708-25-00020

BLOCK ASS'Y,REAR

9

708-25-13151

BLOCK,CYLINDER

10

708-25-13621

PLATE,REAR

|10

708-25-13220

PLATE,REAR

11

720-68-19610

PIN,DOWEL

12

708-25-13140

RING,SNAP

13

708-25-13120

WASHER

14

708-25-13130

SPRING

15

708-25-13441

RETAINER

16

708-25-05061

SPACER KIT

|16

SPACER¤ 11.575MM

|16

SPACER¤ 11.540MM

|16

SPACER¤ 11.560MM

17

708-25-13470

SCREW

18

01643-30623

WASHER

19

708-25-13422

RETAINER,SHOE

20

708-25-13312

PISTON SUB ASS'Y

|20

708-25-13311

PISTON SUB ASS'Y

21

708-25-13630

RING

|22

708-25-00041

CRADLE ASS'Y,REAR

|22

708-25-00040

CRADLE ASS'Y,REAR

|22

708-25-00490

CRADLE SUB ASS'Y,REAR

22

CRADLE,REAR

23

PLUG

24

708-25-13411

CAM,ROCKER

|24

708-25-13410

CAM,ROCKER

25

708-25-14121

SLIDER

26

708-25-12360

PLATE

27

04020-00820

PIN,DOWEL

28

01010-80816

BOLT

|28

01010-30816

BOLT

29

708-25-12330

JOINT

30

07000-12015

O-RING

31

708-25-12340

O-RING

32

708-25-12350

BOLT
