Запчасти Komatsu PC1600-1-A БЛОК КОНДИЦИОНЕРА (/)(№9-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

Схема запчастей Komatsu PC1600-1-A - БЛОК КОНДИЦИОНЕРА (/)(№9-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ
1
2
3
4
5
6
6A
7
8
9
10
10
10
10
10
10
11
12
13
14
15
16
16
16
17
18
19
20
21
21
21
21
21
21
21
21
21
21
21
22
23
24
25
26
27
27
28
29
30
30
31
31
32
33
34
35
35
36
37
38
39
39
40
41
42
43
44
45
46
47

Артикул

Название

Примечание

Количество

G-1

21T-979-X200

AIR CONDITIONER G.,(LOW CAB)

|1

195-911-7201

AIR CONDITIONER UNIT

|1

195-911-7200

AIR CONDITIONER UNIT

|1

195-911-7211

UNIT ASS'Y

|1

195-911-7210

UNIT ASS'Y

1

195-Z11-5511

CASE ASS'Y

2

195-Z11-5520

RADIATOR ASS'Y

3

195-911-7220

EVAPORATOR ASS'Y

4

195-Z11-5680

COVER

5

195-Z11-5930

STAY

6

195-Z11-5740

VALVE ASS'Y

6A

195-Z11-6640

BUSHING

7

195-Z11-5760

HOSE

8

195-Z11-5770

HOSE

9

195-Z11-5750

HOSE

10

145-Z79-6560

CLIP

11

195-Z11-5820

PIPE

12

195-Z11-5830

PIPE

13

195-Z11-6230

THERMISTOR

14

195-Z11-6160

BRACKET

15

195-Z11-6170

GROMMET

16

195-Z11-5950

BAND

17

195-Z11-5780

GROMMET

18

195-Z11-6120

CLAMP

19

195-Z11-7160

CLAMP

20

195-Z11-5910

COVER

21

01010-80616

BOLT

22

01010-80816

BOLT

23

195-Z11-5790

GROMMET

24

195-Z11-5970

CLAMP

25

195-Z11-6110

CLAMP

26

195-911-7240

ELBOW

27

195-911-7250

NUT

28

195-911-7260

WASHER

29

195-911-7270

ELBOW

30

195-911-7280

NUT

31

195-911-7290

WASHER

32

ND146741-2680

ORNAMENT

33

ND146741-2570

ORNAMENT

34

195-911-5611

TUBE,SUCTION

35

195-Z11-5730

PACKING

36

195-911-7320

TUBE

37

17M-911-4710

VALVE,EXPANSION

38

ND949140-2690

O-RING

39

195-911-7310

TUBE

40

195-Z11-5980

CLIP

41

195-Z11-6130

CLAMP

42

195-Z11-6140

CLAMP

43

195-Z11-5990

CLIP

44

195-Z11-5720

HOLDER

45

195-Z11-6291

DUCT,AIR

46

01010-80816

BOLT

47

ND046218-0080

INSULATOR

Выбрано товаров: 53
