Запчасти Komatsu PC1600-1-A КЛАПАН ХОДА РРС ТРУБЫ (ДЛЯ НИЗ. КАБИНА) ГИДРАВЛИКА

1

21T-62-77331

ELBOW

2

07002-03034

O-RING

3

07235-10422

ELBOW

4

07002-02034

O-RING

5

21T-62-87930

ADAPTER

6

21T-60-12910

VALVE ASS'Y

7

07238-10422

CONNECTOR

|7

07238-00422

CONNECTOR

8

07230-20315

UNION

|8

07230-10315

UNION

9

07002-02034

O-RING

10

209-62-57650

UNION

11

07002-02034

O-RING

|12

21T-62-87910

HOSE ASS'Y

|12

21T-62-77231

HOSE ASS'Y

12

07102-20424

HOSE (P)

|12

07102-20413

HOSE (P)

13

07102-20424

HOSE (T)

|13

07102-20413

HOSE (T)

14

07102-20326

HOSE (F)

|14

07102-20319

HOSE (F)

15

07102-20326

HOSE (E)

|15

07102-20319

HOSE (E)

16

07102-20326

HOSE (H)

|16

07102-20319

HOSE (H)

17

07102-20326

HOSE (G)

|17

07102-20319

HOSE (G)

18

01010-80825

BOLT

19

01643-30823

WASHER

20

21K-03-11190

CLIP

|20

21K-03-11190

CLIP

21

01010-81225

BOLT

22

01643-31232

WASHER

23

21T-919-5890

TUBE

|23

21T-62-77780

TUBE

24

21T-919-6350

TUBE

|24

21T-62-77790

TUBE

25

21T-62-77760

BRACKET

26

21T-62-77770

BRACKET

27

01010-81230

BOLT

28

01643-31232

WASHER

29

21T-62-77750

CLAMP

30

01010-81040

BOLT

31

01643-31032

WASHER

32

07102-20205

HOSE

33

175-79-82720

NIPPLE

34

07002-02034

O-RING

35

01010-81075

BOLT

36

01643-31032

WASHER

37

07040-12012

PLUG

38

07002-02034

O-RING
