Запчасти Komatsu PC160-6K ДВОЙН. БАК (ТОПЛИВН. И ГИДРАВЛ МАСЛ.)(№K-) ТОПЛИВН. БАК. AND КОМПОНЕНТЫ

|1

21P-04-K2180

TANK ASS'Y

|1

21P-04-K1167

TANK ASS'Y

1

TANK ASS'Y

|1

TANK ASS'Y

2

205-04-71140

STRAINER

3

203-60-52260

STRAINER

4

203-60-52250

VALVE ASS'Y

5

175-60-27340

SPRING

6

07000-05155

O-RING

7

20E-60-K4620

PLATE

8

01010-81225

BOLT

9

01643-31232

WASHER

10

203-60-56250

STRAINER

11

203-60-56270

O-RING

12

20Y-60-K1270

ROD

13

12R-60-11230

SPRING

14

07000-05180

O-RING

15

20E-60-K4630

PLATE

16

01010-81235

BOLT

17

01643-31232

WASHER

18

20Y-60-21340

GASKET

19

20Y-60-21460

NECK

20

01220-40516

SCREW

21

01601-20513

WASHER

22

07270-61512

TUBE

23

07285-00155

CLIP

24

07040-12412

PLUG

25

07002-12434

O-RING

26

20Y-60-K1480

GAUGE

27

20Y-04-11160

CAP

28

17A-60-11310

CAP ASS'Y

29

7861-92-5810

SENSOR,FUEL

30

07000-03050

O-RING

31

01010-80612

BOLT

32

01643-30623

WASHER

33

21P-04-K1110

TUBE

34

07005-01212

GASKET

35

07206-30812

BOLT

36

20Y-04-11130

VALVE

37

07063-51100

ELEMENT

38

20Y-04-21220

GAUGE

39

20N-60-41360

BOLT

40

20N-60-41371

GASKET

41

01010-81635

BOLT

42

01643-31645

WASHER

43

150-95-27160

GROMMET
