Запчасти Komatsu PC160-6K СОЛЕНОИДНЫЙ КЛАПАН(№K-K999) ГИДРАВЛИКА

1

20E-60-K1351

VALVE ASS'Y

2

20Y-60-22121

SOLENOID VALVE

3

702-21-07010

VALVE ASS'Y

4

07000-02011

O-RING

5

700-93-11320

O-RING

6

203-60-62230

BOLT

7

07040-11007

PLUG

8

07002-11023

O-RING

9

07230-20422

UNION

10

07002-12034

O-RING

11

21P-62-K3320

NIPPLE

12

07040-11409

PLUG

13

07002-11423

O-RING

14

07230-20210

UNION

15

07002-11423

O-RING

16

07230-20210

UNION

17

07002-11423

O-RING

18

20E-62-K2560

BRACKET

19

01010-51240

BOLT

20

01643-31232

WASHER

21

21P-06-K1240

BRACKET

22

01010-51025

BOLT

23

01643-31032

WASHER

24

01010-51035

BOLT

25

01643-31032

WASHER

26

20E-62-K4240

ELBOW

27

20E-62-K4330

SEAL

28

20E-62-K4350

O-RING

29

20E-62-K2680

BLOCK

30

20E-62-K2880

O-RING

31

01010-50650

BOLT

32

01643-30623

WASHER

33

01643-30823

WASHER

34

21P-62-K2160

CONNECTOR

35

07002-11423

O-RING

36

203-62-63271

CLIP

37

01010-51220

BOLT

38

01643-31232

WASHER

39

08036-01814

CLIP

40

01010-51220

BOLT

41

01643-31232

WASHER

42

08034-00536

BAND

43

08036-01814

CLIP
