Запчасти Komatsu PC15R-8 ТОПЛИВН. ЛИНИЯ ВПРЫСКА ДВИГАТЕЛЬ

Схема запчастей Komatsu PC15R-8 - ТОПЛИВН. ЛИНИЯ ВПРЫСКА ДВИГАТЕЛЬ
43
45
A
B
C
28
29
36
30
35
41
38
34
35
37
35
40
38
35
2
37
35
7
39
11
26
23
1
8
9
33
10
32
31
3
32
6
35
44
45
42

Артикул

Название

Примечание

Количество

\0

871070043

MOTOR, ASSY. (3D68-N3FBE)

1

YM719255-53100

FUEL INJECTION VALVE, ASSY.

2

YM129155-61830

O-RING

3

YM119620-53000

FUEL INJECTION NOZZLE, ASSY.

6

YM119620-53080

NUT

7

YM119255-53100

FUEL INJECTION NOZZLE, ASSY.

8

YM119620-53120

SPRING

9

YM114250-53130

SEAT

10

YM119620-53140

SPACER, VALVE STOP

11

YM114250-53400

KIT, SHIM

23

YM129150-59120

RETAINER, PIPE

26

YM129150-59131

BOLT

28

YM119266-59811

INJECTION PIPE N. 1

29

YM119266-59821

INJECTION PIPE N. 2

30

YM119266-59831

INJECTION PIPE N. 3

31

YM724767-59080

PIPE, ASSY.

32

YM124766-59050

CLAMP

33

YM124767-59080

PIPE

34

YM119266-59540

PIPE, FUEL, ASSY.

35

YM124066-59100

CLAMP

36

YM119260-59520

JOINT

37

YM119260-59530

JOINT

38

YM105025-59550

PIPE, FUEL RETURN

39

YM119000-59560

PIPE, FUEL RETURN

40

YM22190-140002

GASKET

41

YM119620-59700

NUT

42

YM119266-59501

SWIVEL JOINT, ASSY.

43

YM119266-59570

JOINT

44

YM119266-59580

BOLT, PIPE JOINT

45

YM22190-080002

GASKET

Выбрано товаров: 30
