Запчасти Komatsu PC15R-8 ТОПЛИВН. ЛИНИЯ ВПРЫСКА ДВИГАТЕЛЬ

\0

871070020

MOTOR, ASSY. (3D68E-N3FB)

1

YM719255-53100

FUEL INJECTION VALVE, ASSY.

2

YM129155-61830

O-RING

3

YM119620-53000

FUEL INJECTION NOZZLE, ASSY.

6

YM119620-53080

NUT

7

YM119255-53100

FUEL INJECTION NOZZLE, ASSY.

8

YM119620-53120

SPRING

9

YM114250-53130

SEAT

10

YM119620-53140

SPACER, VALVE STOP

11

YM114250-53400

KIT, SHIM

18

YM129150-59120

RETAINER, PIPE

21

YM129150-59131

BOLT

23

YM119266-59811

INJECTION PIPE N. 1

24

YM119266-59821

INJECTION PIPE N. 2

25

YM119266-59831

INJECTION PIPE N. 3

26

YM124766-59050

CLAMP

27

YM119266-59540

PIPE, FUEL, ASSY.

28

YM124066-59100

CLAMP

29

YM119260-59520

JOINT

30

YM119260-59530

JOINT

31

YM105025-59550

PIPE, FUEL RETURN

32

YM119000-59560

PIPE, FUEL RETURN

33

YM124767-59080

PIPE

34

YM23414-140000

GASKET

35

YM119620-59700

NUT

36

YM119266-59501

SWIVEL JOINT, ASSY.

37

YM119266-59570

JOINT

38

YM119266-59580

BOLT, PIPE JOINT

39

YM23414-080012

GASKET
