Запчасти Komatsu PC15R-8 ТОПЛИВН. ЛИНИЯ ДВИГАТЕЛЬ

\0

871070020

MOTOR, ASSY. (3D68E-N3FB)

1

YM121520-01851

GASKET

2

YM121520-01860

COVER

3

YM26106-060162

BOLT PLATED

4

YM119255-55620

FILTER, ASSY.

5

YM104200-55330

SPRING

6

YM119810-55340

LEVER

7

YM121254-55510

TANK

8

YM102103-55520

O-RING

9

YM110250-55610

RING, NUT

10

YM121250-55620

SPRING

11

YM124550-55700

CARTRIDGE

12

YM104200-55750

SCREW

13

YM24311-240100

O-RING

14

YM26014-080702

SCREW

15

YM123482-01900

PLUG

16

YM124766-59050

CLAMP

17

YM119462-59190

VALVE, ASSY.

20

YM23414-080012

GASKET

21

YM119225-52102

FUEL FEED PUMP, ASSY.

22

YM129052-55630

STRAINER, FUEL OIL

23

YM22190-080002

GASKET

24

YM22190-080002

GASKET

25

YM119244-59020

PIPE, FUEL, ASSY.

26

YM104264-59030

JOINT

27

YM124766-59050

CLAMP

28

YM121522-59100

PIPE

29

YM104264-59030

JOINT

30

YM119230-59031

PIPE, FUEL, ASSY.

31

YM101304-59020

UNION

32

YM124766-59050

CLAMP

33

YM119230-59080

PIPE

34

YM105582-59150

BOLT, PIPE JOINT

35

YM104200-59170

GASKET
