Запчасти Komatsu PC15R-8 ГИДР. НАСОС. (/) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

\0

3F0755051

HYDRAULIC PUMP, ASSY.

1

CASE, PUMP

2

840141012

SHAFT

\2

840141013

ROTARY GROUP, ASSY.

3

CYLINDER BLOCK

4

PLATE VALVE

\4

840141014

PISTON, ASSY.

5

PISTON

6

SLIDE BLOCK

7

840141015

PLATE

8

840141016

SLEEVE

9

PIN

10

840141017

SPRING

11

840141018

RING, SNAP

12

840141019

RING, SNAP

13

840141020

PLATE

14

840141021

BALL

\14

840141022

KIT, GASKET

15

840141023

GASKET

16

840141024

RING, SNAP

17

O-RING

18

O-RING

19

840141025

WASHER

20

840141029

PIN

21

840141032

BEARING

22

BEARING

23

840141033

RING, SNAP

24

840141034

RING, SNAP

25

844141035

PLUG

26

844141035

PLUG

27

844141041

SCREW

28

844141042

SCREW

29

844141043

NUT
