Запчасти Komatsu PC15R-8 КАБИНА (/) ЧАСТИ КОРПУСА И КАБИНА

\0

3F0547056

OPERATOR'S CAB, ASSY.

1

816214744

WINDOWS, R.H., ASSY.

2

3F0547618

GLASS-WINDOW, RUN REAR

3

816214749

SEAL

4

3F0547617

GLASS-WINDOW, RUN, FRONT

5

816214748

GASKET, FRAME

6

816214747

FRAME

7

816214790

RETAINER

8

816214151

GASKET, FRAME

9

816214745

SEAL, LATERAL GLASS-WINDOW

10

816214147

HANDLE, ASSY.

11

3F0547622

GLASS, LOWER, R.H.

12

3F0547615

GLASS, UPPER

13

3F0547616

GLASS, REAR

14

816214757

WINDOWS, L.H., ASSY.

15

3F0547619

GLASS, LATERAL, L.H.

16

816214741

GASKET

17

816214742

HINGE

18

816214605

PIN

19

816214707

PIN

20

816214709

RING, SNAP

21

816214708

FITTING

22

816214606

WASHER

23

801200021

SCREW

24

816213868

PLUG

25

816213301

SPACER

26

816213300

RUBBER

27

816213302

WASHER

28

801920104

NUT

29

801920051

COVER

30

816214615

HANDLE

31

816214743

GASKET

32

801852208

NUT

33

802070008

WASHER

34

801920051

COVER

35

801250060

SCREW

36

816214721

COVER

37

801852206

NUT

38

801920050

COVER

39

816214705

STRIKER

40

801250059

SCREW

41

802120006

SPRING WASHER

42

802090006

WASHER

43

801703206

NUT
