Запчасти Komatsu PC15R-8 КАБИНА (/) ЧАСТИ КОРПУСА И КАБИНА

\0

3F0547069

OPERATOR'S CAB, ASSY.

1

3F0547731

GLASS, UPPER

2

3F0547732

GLASS, LOWER

3

3F0547074

FRAME, DOOR

4

3F0547761

GASKET

5

3F0547762

PANEL

6

SCREW

7

WASHER

8

3F0547738

BRACKET

9

801014065

BOLT

10

802070008

WASHER

11

801920050

COVER

12

WASHER

13

3F0547765

PIN

14

3F0547766

WASHER

15

802250006

RING, SNAP

16

3F0547739

BRACKET

17

816215049

ROLLER

18

816215048

ROLLER

19

NUT

20

816215069

PLATE

21

801703408

NUT

22

816214657

WASHER

23

3F0547740

BRACKET

24

801200018

SCREW

25

816215044

HANDLE, EXTERNAL, L.H.

26

801852206

NUT

27

801250044

SCREW

28

816215055

HANDLE

29

3F0547726

TIE-ROD

30

816215054

CLAMP

31

816215056

LOCK, ASSY.

32

3F0547727

TIE-ROD

33

816215046

LOCK, ASSY.

34

3F0547746

SHIM

35

801200021

SCREW

36

3F0547744

SLIDER

37

3F0547728

TIE-ROD

38

816215047

CLAMP

39

816215045

LOCK, ASSY.
