Запчасти Komatsu PC15R-8 УПРАВЛЯЮЩ. КЛАПАН (/) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

\0

3F0765053

CONTROL VALVE, ASSY.

1

890001578

SCREW

2

890001579

RETAINER

3

890001580

RETAINER

4

890001581

SPRING

5

890001582

O-RING

6

890001583

SCREW

7

890001585

COVER

8

890001586

COVER

9

890001587

RETAINER

10

890001589

SCREW

11

890001591

SCREW

12

890001593

COVER

13

890001055

GASKET

14

890001594

PLATE

15

890001595

RETAINER

16

890001596

WASHER

17

BALL

18

SEAT

19

O-RING

20

890001597

SCREW

21

890001022

SPRING

22

890001599

COVER

23

890001600

COVER

24

890001601

PLATE

25

890001602

VALVE

26

890001603

SPRING

27

890001604

PLUG

28

890001239

O-RING

29

PLUG

30

PLUG

31

O-RING

32

VALVE

33

SPRING

34

PLUG

35

PLUG

36

890001605

RETAINER

37

890001609

SCREW

38

890001608

PLUG

39

890001270

O-RING
