Запчасти Komatsu PC15R-8 МОТОР ХОДА (/) (ВНУТР. ЧАСТИ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$0

20W-60-32001

MOTOR ASS'Y

1

FUFZD8105201

BODY

2

FUFRP096102

COVER

3

CARRIER

4

FUFRP118506

GEAR

5

GEAR

6

FUFRP-0961-08

GEAR

7

FUFZD8393109

GEAR

8

PIN

9

PIN

10

FUFZD8105212

RING,SEAL

11

FUFRP0961113

RING,SNAP

12

FUFRP147414

COLLAR,THRUST

13

FUFRP096116

NEEDLE

14

FUFRP-0961-17

NEEDLE

15

FUES100110

SEAT,FLOATING

16

O-RING

17

FU7819W1V

BEARING

18

FUFRP096221

WASHER,THRUST

19

FUFRP096122

RING,SNAP

20

FURA26

RING,SNAP

21

FURA13

RING,SNAP

22

FUFRP096126

RING,SNAP

23

04025-00312

PIN,SPRING

24

FUROA25170

O-RING

25

FUROA24870

O-RING

26

FUTPHA-1/8

PLUG

27

NAME PLATE,NAME

28

MOTOR

29

FUFRP147434

WASHER,THRUST

30

FUFRP146437

RING,SNAP

31

FUPPH7-4X6

PIN

KIT

FUGHB18105

BODY SUB ASS'Y

1

FUFZD8105201

BODY

17

FU7819W1V

BEARING

22

FUFRP096126

RING,SNAP

KIT

FUGHC10028393

CARRIER SUB ASS'Y

3

CARRIER

5

GEAR

6

FUFRP-0961-08

GEAR

9

PIN

14

FUFRP-0961-17

NEEDLE

18

FUFRP096221

WASHER,THRUST

20

FURA26

RING,SNAP

23

04025-00312

PIN,SPRING

30

FUFRP146437

RING,SNAP
