Запчасти Komatsu PC15R-8 МОТОР ПОВОРОТА ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$0

20M-60-83001

MOTOR ASS'Y

1

STAD0898C

HOUSING,BEARING

2

STAD0882C

MOUNTING,FLANGE

3

STD0899B

GEAR,PINION

4

STA42041

PLUG

5

STAD0889B

PISTON

6

STAD0888B

RING

7

STAD0885B

PLATE

8

STAD0911A

PLATE

9

STAD0918B

PLATE

10

STAE134A-1

SPRING

11

STAA0006A-5

BEARING,FRONT

12

04065-01030

RING

13

04064-04518

RING

14

STAD0789A

BEARING,REAR

15

STAA0032A-47

RING

16

STADO320A

X-RING

17

07000-12015

O-RING

18

07000-12090

O-RING

19

STAA0033A-30

BOLT

20

ST9050

SEAL,SHAFT

21

ST7403CH-504

ROLLER

22

STD0633C-10

DRIVE

23

ST8432S-6

PLATE,VALVE

24

ST8433

SHAFT,VALVE

25

ST8915-1

RING,BALANCER

26

ST7383

SPRING

27

ST9135-1

SEAL,INNER FACE

28

ST14351

PIN

29

ST9135-2

SEAL,OUTER FACE

30

ST9022S-6

O-RING

31

ST9022S-2

O-RING

32

STAS568-011

O-RING

33

ST14314

BOLT

34

PLATE

35

RIVET,NAME

36

STDWD128A

PLUG

37

STAD0884A

COLLER

|$38

STAD0901C-001

VALVE HOUSING ASS'Y

38

HOUSING,VALVE

39

CARTRIDGE

40

VALVE,SEAT

41

VALVE,NEEDLE

42

SEAT,SPRING

43

WEIGHT,SPRING

44

PLUG,ORIFICE

45

PACKING

46

PLUG

47

SPRING

48

07000-11005

O-RING

49

07000-12020

O-RING

50

SCREW

51

NUT

52

NUT

53

PLUG

54

07000-12014

O-RING

55

SPRING

56

BALL,STEEL
