Запчасти Komatsu PC15R-8 РУКОЯТЬ (QUICK ГИДРОМОЛОТ РУКОЯТЬ СПЕЦ-Я.) РАБОЧЕЕ ОБОРУДОВАНИЕ

|$1

20W-970-3371

ARM ASS'Y,1ST

1

20W-970-3383

ARM

2

20A-70-11120

BUSHING

3

20A-70-12221

SEAL

4

20M-970-8312

ARM,2ND

4

20M-970-8321

BRACKET,L.H. (WELDED)

4

20M-970-8331

BRACKET,R.H. (WELDED)

5

20M-970-8620

PIN

6

04082-00110

LOCK

7

01010-81020

BOLT

8

01643-31032

WASHER

9

20M-970-8781

PIN

10

20P-971-7460

PIN,LINCH

11

20M-970-8201

BREAKER ASS'Y

12

20M-970-7850

PLATE

13

01010-81020

BOLT

14

01643-31032

WASHER

15

20M-970-7223

BOLT

16

01643-32460

WASHER

17

01582-12419

NUT

18

20M-970-7920

SHIM, 1.0MM

19

20M-970-7930

SHIM, 2.0MM

20

20M-970-7940

SHIM, 3.0MM

21

20M-970-8911

HOSE

22

20M-973-1730

ELBOW

23

20M-970-7160

CHISEL

23

20M-970-7550

PIN,LOCK

23

20P-971-7460

PIN,RING

24

20M-70-81322

PIN

25

20N-70-11280

SPACER, 1.0MM

26

04082-00110

LOCK

27

01010-81020

BOLT

28

01643-31032

WASHER
