Запчасти Komatsu PC15R-8 DELUXE КОЖУХ ШЕСТЕРЕН. ПЕРЕДАЧИ ДВИГАТЕЛЬ

\0

871070043

ENGINE, ASSY.

1

YM719266-01622

HOUSING ASSY., GEAR

3

YM119620-01800

GASKET, BONNET

4

YM119266-01590

HOUSING ASSY., GEAR

6

YM119266-32000

PUMP, HYDRAULIC OIL

7

YM26106-060252

SCREW

8

YM26216-080202

STUD

9

YM977770-01212

GASKET, LIQUID

10

YM119636-01740

COVER

11

YM119636-01750

GASKET

12

YM119266-01910

PIPE, KNOCK

13

YM119624-32040

O-RING

14

YM26106-060122

SCREW

15

YM26106-060202

BOLT

16

YM26106-060352

BOLT

17

YM26106-060602

BOLT PLATED

18

YM26106-060652

BOLT

19

YM124160-01751

PLUG

20

YM24311-000320

O-RING

21

YM121023-01550

COVER

22

YM24341-000240

O-RING

23

YM26106-060162

BOLT PLATED

24

YM119660-01551

COVER

25

YM119660-01562

GASKET

26

YM119266-01840

HOUSING

27

YM121450-01560

STUD

28

YM119660-01570

STUD

30

YM22351-040010

PIN

31

YM26116-050082

BOLT

32

YM119266-01880

COVER

33

YM119266-01890

GASKET

34

YM26366-060002

NUT

35

YM119623-01950

SHIM

44

YM194990-22050

NUT

45

YM119266-01870

GASKET

46

YM26366-080002

NUT

47

YM119209-01550

BOLT

48

YM26106-060162

BOLT

49

YM22190-060003

GASKET
