Запчасти Komatsu PC15R-8 DELUXE ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ

\0

871070043

ENGINE, ASSY.

1

YM23065-120700

PIPE

2

YM119260-07900

LIFTER

3

YM26106-080142

BOLT

4

YM22351-060012

PEG

5

YM119266-11710

HEAD,ASSY.

6

HEAD, ASSY.

8

YM119260-11800

GUIDE VALVE

11

YM119620-11080

SEAT, SUCTION VALVE

12

YM23876-005000

PLUG

13

YM27241-350000

PLUG

14

YM119266-11100

VALVE, SUCTION

15

YM119260-11110

VALVE, EXHAUST

16

YM114250-11120

SPRING, VALVE

17

YM114250-11180

RETAINER, SPRING

18

YM714250-11570

COTTER, ASSY.

20

YM119260-11340

SEAL, VALVE STEM

21

YM119260-11370

CAP VALVE

22

YM119600-11450

PROTECTION, NOZZLE

23

YM119600-11460

GASKET

24

YM119260-11200

ROCKER SHAFT, ASSY.

25

YM119260-11240

ROCKER SHAFT

28

YM119260-11260

SUPPORT

29

YM119260-11270

SCREW

30

YM119260-11280

SPRING

31

YM719260-11650

ROCKER SHAFT, SUCTION

32

YM105010-11230

SCREW

34

YM26756-060002

NUT

35

YM719260-11660

ROCKER SHAFT, EXHAUST

36

YM105010-11230

SCREW

38

YM26756-060002

NUT

39

YM22242-000100

CIRCLIP

40

YM119265-11260

SUPPORT

41

YM26106-080452

BOLT

42

YM26366-080002

NUT

43

YM124160-01751

PLUG

44

YM119266-11531

BONNET ASSY., HEAD

45

YM24311-000320

O-RING

47

YM119266-11390

JOINT

48

YM119266-03200

PLATE

49

YM119266-03210

GASKET

50

YM22857-500100

SCREW

51

YM119266-11310

GASKET, BONNET

52

YM124160-11360

PLUG

53

YM24311-000120

O-RING

54

YM129795-77800

PLUG

55

YM119645-77820

CONNECTION PLUGS

56

YM119620-11350

STUD
