Запчасти Komatsu PC15MRX-1 ОСНОВН. КЛАПАН (8-КЛАПАН) (/9) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

723-18-14302

CONTROL VALVE

1

723-11-17361

BOLT

2

723-11-17353

RETAINER

3

723-11-17330

RETAINER

4

723-11-17341

SPRING

5

723-11-17770

SPRING

6

723-11-17780

SPRING

7

723-11-17790

RETAINER

8

722-12-19120

O-RING

9

01252-60640

BOLT

10

723-11-17410

CASE,SPRING

11

723-11-17290

CASE,SPRING

12

723-11-17431

RETAINER

13

01252-60620

BOLT

14

01252-60612

BOLT

15

723-11-17160

CASE,SPRING

16

709-32-11530

SEAL

17

723-11-17130

PLATE

18

723-11-17280

RETAINER

19

723-11-17150

WASHER

20

BALL

21

SEAT

22

O-RING

23

01252-60610

BOLT

24

723-11-17440

SPRING

25

709-32-11580

SPRING

26

723-11-17540

SPRING

27

723-11-17320

CASE,SPRING

28

723-11-17310

PLATE

29

723-11-28190

VALVE

30

723-11-28221

SPRING

31

723-11-17450

PLUG

32

07002-12434

O-RING

33

PLUG

34

PLUG

35

PLUG

36

O-RING

37

POPPET

38

SPRING

39

PLUG

40

PLUG

41

723-11-17591

RETAINER

42

01252-60616

BOLT

43

07040-11409

PLUG

44

07002-11423

O-RING

45

706-73-71450

PLUG

46

07002-11423

O-RING

47

723-11-17370

CASE,SPRING
