Запчасти Komatsu PC158US-2 ЦИЛИНДР РУКОЯТИ(YELНИЗ.) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

203-63-X9040

CYLINDER GROUP

|1

203-63-02722

CYLINDER ASS'Y,ARM

1

203-63-65142

CYLINDER,ARM

2

707-76-70240

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

707-71-32530

COLLAR

5

07000-15105

O-RING (KIT)

6

707-35-91150

RING,BACK-UP (KIT)

7

707-27-11971

HEAD,CYLINDER

8

707-52-90500

BUSHING

9

707-51-75030

PACKING,ROD (KIT)

10

707-51-75630

RING,BUFFER (KIT)

11

07000-15105

O-RING (KIT)

12

707-35-91150

RING,BACK-UP (KIT)

13

144-63-94170

SEAL,DUST (KIT)

14

07179-13089

RING,SNAP

15

01010-81670

BOLT

16

01643-51645

WASHER

17

203-63-65121

ROD

18

707-71-60200

PLUNGER

19

04260-00635

BALL

20

707-71-91270

CAP

21

707-76-70240

BUSHING

22

07145-00070

SEAL,DUST (KIT)

23

707-71-60870

PLUNGER

24

707-36-11661

PISTON

25

707-44-11280

RING,PISTON (KIT)

26

707-39-11510

RING,WEAR (KIT)

27

707-44-11920

RING

28

01310-01216

SCREW

29

07000-15070

O-RING (KIT)

30

707-35-90360

RING,BACK-UP (KIT)

30A

707-83-13010

VALVE

30B

07750-01628

SPRING

30C

707-87-14070

PLUG

30D

07002-12034

O-RING

31

203-63-65171

TUBE

32

707-87-13570

ELBOW

33

07000-13025

O-RING (KIT)

34

01010-50850

BOLT

35

01010-50855

BOLT

36

01643-50823

WASHER

37

707-88-95360

BAND

38

707-88-95510

BRACKET

39

01010-51035

BOLT

40

01643-51032

WASHER

41

07283-22236

CLIP

42

01599-01011

NUT

43

01643-31032

WASHER

|K

707-99-44230

SERVICE KIT
