Запчасти Komatsu PC150LC-6K КЛАПАН PPC(ХОД) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

702-16-01430

PILOT VALVE

1

BODY,VALVE

2

VALVE

3

702-16-51140

SHIM¤ 0.30MM

4

702-16-53420

SPRING

5

702-16-53140

RETAINER

6

702-16-54420

SPRING

7

702-16-53170

PISTON

8

702-16-51270

SEAL

9

702-16-54170

COLLAR

10

07000-02020

O-RING

11

PLATE

12

LEVER

13

702-16-54280

SEAL,DUST

14

702-16-54430

BUSHING

15

04025-00432

PIN,SPRING

16

702-16-54310

CASE

17

01010-80855

BOLT

18

01643-30823

WASHER

19

01010-80816

BOLT

20

702-16-54331

WASHER¤ 1.60MM

|20

702-16-54341

WASHER¤ 1.30MM

|20

702-16-54351

WASHER¤ 1.00MM

21

SHAFT

22

01252-30525

BOLT

23

702-16-54510

PLATE

24

04025-00420

PIN,SPRING

25

LEVER

26

01224-40612

SCREW

27

PLUG

28

PLUG

|29

702-16-54500

DAMPER ASS'Y

29

CASE

30

PISTON

31

O-RING

32

WASHER

33

RING

34

SCREW
