Запчасти Komatsu PC150LC-6K МОТОР ХОДА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC150LC-6K - МОТОР ХОДА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
5
6
7
8
8
9
9
10
10
11
12
13
14
15
16
16
17
17
18
19
20
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
B
B
B
B
B

Артикул

Название

Примечание

Количество

|1

21P-60-K1171

MOTOR ASS'Y,TRAVEL

|1

21P-60-K1430

VALVE ASS'Y,CONTROL

1

21P-60-K1940

PLATE

2

21P-60-K1950

PISTON

3

21P-60-K1960

TRUNNION

4

21P-60-K1970

BUSHING

5

21P-60-K1980

PISTON

6

21P-60-K1990

SPRING

7

21P-60-K2010

SCREW

8

21P-60-K2020

SCREW

9

21P-60-K2030

SCREW

10

21P-60-K1890

PIN

11

21P-60-K2040

SCREW

12

21P-60-K4470

RETAINER

13

21P-60-K2170

SCREW

14

21P-60-K2180

SCREW

15

21P-60-K2190

PIN

16

21P-60-K2210

SCREW (KIT)

17

21P-60-K2220

SCREW (KIT)

18

21P-60-K2230

O-RING (KIT)

19

21P-60-K2240

O-RING (KIT)

20

21P-60-K2250

PIN

21

21P-60-K2260

RING,SNAP

22

21P-60-K4430

BOLT

23

21P-60-K2310

PLUG

24

21P-60-K2050

PISTON

25

21P-60-K2060

SCREW

26

21P-60-K2070

SPRING

27

21P-60-K2080

WASHER

28

21P-60-K2270

O-RING

29

21P-60-K2090

SCREW

30

21P-60-K2130

BUSHING

31

21P-60-K2280

BALL

32

21P-60-K2140

POPPET

33

21P-60-K2150

SCREW

34

21P-60-K2160

SPRING

35

21P-60-K2290

O-RING (KIT)

36

21P-60-K2310

PLUG (KIT)

37

21P-60-K1920

VALVE ASS'Y,CONTROL

38

21P-60-K1930

VALVE ASS'Y,RELIEF

|38

21P-60-K2370

SEAL KIT (KIT)

|38

21P-60-K2380

CAP (KIT)

K

21P-60-K4480

SERVICE KIT,TRAVEL MOTOR

Выбрано товаров: 43
