Запчасти Komatsu PC150LC-6K МОТОР ПОВОРОТА(№K-K999) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

21P-60-K1181

MOTOR ASS'Y,SWING

1

21P-60-K2690

HOUSING

2

21P-60-K1250

PLATE,VALVE

3

21P-60-K2710

PLUG

4

21P-60-K4560

SEAL,OIL

5

21P-60-K4450

PLUG

6

21P-60-K4460

SEAL

7

21P-60-K2720

HOUSING

8

21P-60-K1260

O-RING

9

21P-60-K3810

O-RING

10

21P-60-K1280

O-RING

11

21P-60-K2730

SEAL

12

21P-60-K1290

SEAL

13

21P-60-K2740

RING,RETAINER

14

21P-60-K4570

PLUG

15

21P-60-K2750

SEAL

16

21P-60-K2760

SHAFT

17

21P-60-K2780

BARREL

18

21P-60-K2790

BEARING,NEEDLE

19

21P-60-K1380

SUPPORT

20

21P-60-K3860

SPRING

21

21P-60-K4580

CAP

22

21P-60-K4590

RING,RETAINER

23

21P-60-K2820

PISTON ASS'Y

24

21P-60-K1310

RING,PISTON

25

21P-60-K4610

PIN,GUIDE

26

21P-60-K2830

RING,GEAR

27

21P-60-K1360

BEARING,BALL

28

21P-60-K1370

BEARING,BALL

29

21P-60-K1390

SPACER¤ 0.5MM

|29

21P-60-K2850

SPACER¤ 0.6MM

|29

21P-60-K2860

SPACER¤ 0.8MM

|29

21P-60-K2840

SPACER¤ 1.0MM

30

21P-60-K2870

RING,RETAINER

31

21P-60-K1410

SHIM¤ 0.2MM

|31

21P-60-K2880

SHIM¤ 0.4MM

|31

21P-60-K2890

SHIM¤ 0.6MM

|31

21P-60-K2910

SHIM¤ 0.8MM

|31

21P-60-K2920

SHIM¤ 1.0MM

32

21P-60-K2940

SCREW

33

21P-60-K2990

PLATE¤ NAME

34

21P-60-K4350

RIVET

35

21P-60-K4360

HOUSING,VALVE

36

21P-60-K1330

O-RING

37

21P-60-K4370

PLUG

38

21P-60-K1340

CARTRIDGE,VALVE

39

21P-60-K4380

PLUG

40

21P-60-K1350

VALVE,CHECK
