Запчасти Komatsu PC150LC-6K ЦИЛИНДР РУКОЯТИ(ДЛЯ 2-СЕКЦИОНН. СТРЕЛЫ)(№K-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

20G-63-K1502

CYLINDER ASS'Y,ARM

|1

21P-63-03120

CYLINDER ASS'Y

1

21P-63-62140

CYLINDER

2

21P-63-62120

ROD,PISTON

3

707-27-12921

HEAD,CYLINDER

4

707-36-12071

PISTON

5

707-71-60860

PLUNGER

6

01310-01216

SCREW

7

707-71-60200

PLUNGER

8

707-71-91270

CAP

9

04260-00635

BALL,STEEL

10

707-71-32870

COLLAR

11

01010-61670

BOLT

12

01643-51645

WASHER

13

707-56-85510

SEAL,DUST

14

07179-13099

RING,SNAP

15

707-51-85030

PACKING

16

707-51-85630

RING,BUFFER

17

07000-15110

O-RING

18

707-35-91220

RING,BACK-UP

19

707-52-90610

BUSHING

20

707-44-12180

RING,PISTON

21

707-39-12110

RING,WEAR

22

07000-15075

O-RING

23

707-35-90930

RING

24

707-44-12911

RING

25

707-76-80230

BUSHING

26

07145-00080

SEAL,DUST

27

07020-00675

FITTING,GREASE

28

707-83-13010

VALVE

29

07750-01628

SPRING

30

07002-12034

O-RING

31

707-87-14070

PLUG

32

20G-62-K1880

TUBE

33

01010-81045

BOLT

34

01010-81060

BOLT

35

01643-51032

WASHER

36

07000-13030

O-RING

37

20G-62-K1891

TUBE

38

707-88-95861

BRACKET

39

707-88-99240

BAND

40

01010-81035

BOLT

41

01643-31032

WASHER

42

07283-22738

CLIP

43

01643-31032

WASHER

44

01599-01011

NUT

45

20G-62-K1910

BRACKET

46

707-88-99210

BAND

47

01010-81035

BOLT

48

01643-31032

WASHER

49

07283-22738

CLIP

50

01643-31032

WASHER

51

01599-01011

NUT
