Запчасти Komatsu PC150LC-6K ОСНОВН. НАСОС (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

21P-60-K1503

PUMP ASS'Y

|1

21P-60-K1502

PUMP ASS'Y

|1

21P-60-K3010

PUMP ASS'Y

|1

21P-60-K3060

REGULATOR ASS'Y

|1

21P-60-K3650

CONTROLLER

1

21P-60-K3820

SOLENOID

|1

21P-60-K3990

SOLENOID

|1

21P-60-K4010

SCREW

2

21P-60-K3830

PISTON

3

21P-60-K3840

SEAT

4

21P-60-K3850

SEAT

5

21P-60-K3860

SPRING

6

21P-60-K3870

COVER

7

21P-60-K3880

BUSHING

8

21P-60-K3890

SLEEVE

9

21P-60-K3910

VALVE

10

21P-60-K3920

COLLAR

11

21P-60-K3930

STUD

12

21P-60-K3940

NUT (KIT A)

13

21P-60-K3950

O-RING

14

21P-60-K3960

O-RING

15

21P-60-K3970

BOLT

16

21P-60-K3980

PLUG

|17

21P-60-K3660

CONTROLLER

17

21P-60-K4020

PLUG

18

21P-60-K4030

PISTON

19

21P-60-K4040

SEAT

20

21P-60-K4050

PISTON

21

21P-60-K4060

SPRING

22

21P-60-K4070

SPRING

23

21P-60-K4080

STUD

24

21P-60-K4090

SLEEVE

25

21P-60-K4110

BUSHING

26

21P-60-K4120

NUT

|26

21P-60-K3940

NUT

27

21P-60-K4130

O-RING (KIT A)

28

21P-60-K4140

PLUG (KIT A)

|29

21P-60-K3670

PISTON ASS'Y

29

21P-60-K4150

PISTON

30

21P-60-K4160

BUSHING

31

21P-60-K4170

SPRING

32

21P-60-K4180

ROLLER

33

21P-60-K3680

HOUSING

34

21P-60-K3690

LEVER

35

21P-60-K3710

PIN

36

21P-60-K3720

BUSHING

37

21P-60-K3730

PLUG

38

21P-60-K3740

BOLT

39

21P-60-K3750

PIN

40

21P-60-K3760

PIN

41

21P-60-K3770

BOLT

42

21P-60-K3780

RING,SNAP

43

21P-60-K3790

O-RING (KIT A)

KIT A

21P-60-K4510

SERVICE KIT
