Запчасти Komatsu PC150LC-6K ПРАВ. ДВЕРЬ (КАБИНА)(№K-K999) ЧАСТИ КОРПУСА

|1

20Y-54-K7404

DOOR ASS'Y

|1

20Y-54-K7403

DOOR ASS'Y

1

20Y-54-K7413

COVER

|1

198-54-41982

LOCK ASS'Y (WELDED)

2

205-54-53550

DOVE TAIL

3

01010-50612

BOLT

4

01643-30623

WASHER

5

01010-51235

BOLT

6

01643-31232

WASHER

7

20Y-54-33290

PLATE

8

20Y-54-K8552

FRAME

|8

20Y-54-K8551

FRAME

9

20Y-54-33170

BRACKET

10

01010-51225

BOLT

11

01643-31232

WASHER

12

205-54-51970

DOVE TAIL

13

01010-50616

BOLT

14

01643-30623

WASHER

15

20Y-54-K7421

PLATE

16

01010-51225

BOLT

17

01643-31232

WASHER

18

20E-54-K2230

BAR

19

01641-21016

WASHER

20

04050-13018

PIN,COTTER

21

20Y-54-11611

STOPPER

22

01580-11008

NUT

23

01010-51230

BOLT

24

01643-31232

WASHER

25

20Y-54-K8121

SHEET

26

20Y-54-K7931

SHEET

27

20Y-54-K7430

SEAL

28

20Y-54-K7441

SEAL

29

207-54-52690

PLATE

30

21P-54-K3131

COVER

31

01010-51225

BOLT

32

01643-31232

WASHER

33

20Y-54-12320

CATCH

34

01010-51230

BOLT

35

124-54-26540

WASHER
