Запчасти Komatsu PC150HD-5K ГИДРОЛИНИЯ (ДОПОЛН. ГИДРОЛИНИЯ ЛИНИЯ) (РУКОЯТЬ)(№K-K9) РАБОЧЕЕ ОБОРУДОВАНИЕ (ЭКСКАВАТ.)

1

07096-20515

HOSE,(FOR 2.1M ARM)

|1

203-62-K1570

HOSE,(FOR 2.5M ARM)

2

07099-21016

HOSE,(FOR 2.1M ARM)

|2

21P-62-K1290

HOSE,(FOR 2.5M ARM)

3

07000-13032

O-RING

4

07371-31049

FLANGE,SPLIT

5

07372-21035

BOLT

6

01643-51032

WASHER

7

203-62-59950

TUBE,(FOR 2.1M ARM)

|7

203-973-5761

TUBE,(FOR 2.5M ARM)

8

202-973-6350

NIPPLE

9

07002-13334

O-RING

10

203-62-59960

TUBE,(FOR 2.1M ARM)

|10

203-973-5770

TUBE,(FOR 2.5M ARM)

11

07000-13032

O-RING

12

07371-31049

FLANGE,SPLIT

13

07372-21035

BOLT

14

01643-51032

WASHER

15

203-973-5750

NIPPLE

16

07002-13334

O-RING

17

203-973-3910

BODY

18

203-973-3920

SPOOL

19

07000-13032

O-RING

20

07001-03032

RING,BACK-UP

21

131-60-16170

WASHER

22

04064-03818

RING,SNAP

23

04260-00793

BALL

24

236-10-12240

SPRING

25

07043-00108

PLUG

26

01010-51075

BOLT

27

01643-31032

WASHER

28

07040-13316

PLUG

29

07002-13334

O-RING

30

203-62-43390

CUSHION

31

203-973-5780

CLAMP

32

203-973-4390

CUSHION

33

203-973-5790

CLAMP

34

01010-51275

BOLT

35

01643-31232

WASHER
