Запчасти Komatsu PC150HD-5K ЦИЛИНДР РУКОЯТИ(№K-K7) РАБОЧЕЕ ОБОРУДОВАНИЕ (ЭКСКАВАТ.)

|1

203-63-K1710

CYLINDER ASS'Y,ARM

1

203-63-K2010

CYLINDER

2

707-76-70240

BUSHING

3

07145-00070

SEAL,DUST

4

203-63-K2030

HEAD,CYLINDER

5

707-52-90500

BUSHING

6

707-51-75030

PACKING,ROD

7

707-51-75630

RING,BUFFER

8

203-63-K2060

O-RING

9

203-63-K2070

RING,BACK-UP

10

144-63-94170

SEAL,DUST

11

203-63-K2090

RING,SNAP

12

203-63-K2120

BOLT

13

203-63-K2020

ROD,PISTON

14

707-76-70240

BUSHING

15

07145-00070

SEAL,DUST

16

203-63-K2140

BUSHING,CUSHION

17

203-63-K2040

PISTON

18

203-63-K2080

O-RING

19

707-44-11280

RING,PISTON

20

707-39-11510

RING,WEAR

21

707-44-11920

RING

22

203-63-K2050

SCREW,SET

23

203-63-K2130

RING,CUSHION

24

203-63-K2110

RING,SNAP

25

203-63-K2660

TUBE

26

203-63-K2250

BLOCK

27

07000-13025

O-RING

28

203-63-K2240

BOLT

29

203-63-K2180

BAND

30

203-63-K2170

BRACKET

31

203-63-K2160

BAND

32

203-63-K2150

BRACKET

33

203-63-K2210

BOLT

34

203-63-K2220

WASHER

35

203-63-K2190

CLIP

36

203-63-K2790

NUT

37

203-63-K2230

WASHER
