Запчасти Komatsu PC150-6K МОТОР ПОВОРОТА(№K-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC150-6K - МОТОР ПОВОРОТА(№K-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
5
6
7
8
9
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
30
31
32
32

Артикул

Название

Примечание

Количество

|1

21P-60-K5190

MOTOR ASS'Y

|1

21P-60-K1183

MOTOR ASS'Y

|1

21P-60-K1182

MOTOR ASS'Y

1

21P-60-K4760

HOUSING

2

21P-60-K1250

PLATE,VALVE

3

21P-60-K2710

PLUG

4

21P-60-K4770

HOUSING,OIL

5

21P-60-K1260

O-RING

6

21P-60-K1270

O-RING

7

21P-60-K1280

O-RING

8

21P-60-K4780

SEAL

9

21P-60-K4790

SEAL

|9

21P-60-K1290

SEAL

10

21P-60-K4810

SPACER,RETAINER¤ (NOT SHOWN)

11

21P-60-K2740

RING

12

21P-60-K4820

RING

13

21P-60-K2750

SEAL

14

21P-60-K4830

SHAFT

15

21P-60-K2770

PIN

16

21P-60-K4840

BARREL

17

21P-60-K4850

SUPPORT

18

21P-60-K2820

PISTON ASS'Y

19

21P-60-K1310

RING,PISTON

20

21P-60-K4860

RING,GEAR

21

21P-60-K1360

BEARING

22

21P-60-K4870

BEARING

23

21P-60-K4880

SPACER¤ 2.35MM

|23

21P-60-K4890

SPACER¤ 2.4MM

|23

21P-60-K4910

SPACER¤ 2.45MM

|23

21P-60-K4920

SPACER¤ 2.5MM

|23

21P-60-K4930

SPACER¤ 2.55MM

|23

21P-60-K4940

SPACER¤ 2.6MM

|23

21P-60-K4950

SPACER¤ 2.65MM

|23

21P-60-K4960

SPACER¤ 2.7MM

|23

21P-60-K4970

SPACER¤ 2.75MM

|23

21P-60-K4980

SPACER¤ 2.8MM

|23

21P-60-K4990

SPACER¤ 2.85MM

|23

21P-60-K5110

SPACER¤ 2.9MM

|23

21P-60-K5120

SPACER¤ 2.95MM

24

21P-60-K2670

RING

25

21P-60-K1410

SHIM¤ 0.2MM

|25

21P-60-K2880

SHIM¤ 0.4MM

|25

21P-60-K2890

SHIM¤ 0.6MM

|25

21P-60-K2910

SHIM¤ 0.8MM

|25

21P-60-K2920

SHIM¤ 1.0MM

|25

21P-60-K2930

SHIM¤ 1.0MM

26

21P-60-K2940

SCREW

27

21P-60-K4360

HOUSING

28

21P-60-K1330

O-RING

29

21P-60-K4370

PLUG

30

21P-60-K5150

CARTRIDGE,VALVE

|30

21P-60-K1340

CARTRIDGE,VALVE

31

21P-60-K4380

PLUG

32

21P-60-K1350

VALVE,CHECK

Выбрано товаров: 54
