Запчасти Komatsu PC150-6K ЦИЛИНДР КОВША ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

21P-63-K1901

CYLINDER ASS'Y,BUCKET

|1

21P-63-K1821

CYLINDER ASS'Y

1

21P-63-74140

SHELL ASS'Y

2

21P-63-74120

ROD ASS'Y,PISTON

3

707-27-11620

HEAD,CYLINDER

4

707-36-11410

PISTON

5

07165-14850

NUT

6

01010-61670

BOLT

7

01643-51645

WASHER

8

144-63-94170

SEAL,DUST

9

07179-13089

RING,SNAP

10

707-51-75030

PACKING,ROD

11

707-51-75630

RING,BUFFER

12

07000-15105

O-RING

13

07001-05105

RING,BACK-UP

14

707-52-90500

BUSHING

15

707-44-11180

RING,PISTON

16

707-39-11110

RING,WEAR

17

707-44-11911

RING

18

707-76-70230

BUSHING

19

07145-00070

SEAL,DUST

20

707-76-70370

BUSHING

21

21K-70-12180

SEAL,DUST

22

07020-00000

FITTING,GREASE

23

07020-00900

FITTING,GREASE

24

21P-63-K2140

TUBE

25

707-88-99110

BAND

26

707-88-87210

BRACKET

27

07282-02288

CLAMP

28

01010-81020

BOLT

29

01643-31032

WASHER

30

01010-81035

BOLT

31

01643-51032

WASHER

32

01010-80850

BOLT

33

707-87-12830

ELBOW

34

07000-13025

O-RING

35

01643-50823

WASHER

36

07000-13030

O-RING

37

01010-81080

BOLT

38

01643-51032

WASHER
