Запчасти Komatsu PC150-6K ЦИЛИНДР СТРЕЛЫ(№K-K999) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

21P-63-K1601

CYLINDER ASS'Y,L.H.

G1

21P-63-K1701

CYLINDER ASS'Y,R.H.

|1

21P-63-K1611

CYLINDER ASS'Y,BOOM

1

21K-63-54140

CYLINDER

2

21K-63-54120

ROD,PISTON

3

707-27-11620

HEAD,CYLINDER

4

707-36-11410

PISTON

5

07165-14850

NUT

6

01010-81670

BOLT

7

01643-51645

WASHER

8

144-63-94170

SEAL,DUST

9

07179-13089

RING,SNAP

10

707-51-75030

PACKING,ROD

11

707-51-75630

RING,BUFFER

12

07000-15105

O-RING

13

07001-05105

RING,BACK-UP

14

707-52-90500

BUSHING

15

707-44-11180

RING,PISTON

16

707-39-11110

RING,WEAR

17

707-44-11911

RING

18

707-76-70330

BUSHING

19

07145-00070

SEAL,DUST

20

707-76-70230

BUSHING

21

07020-00675

FITTING,GREASE

22

707-88-97750

BAND

23

21P-62-K1741

BRACKET,L.H.

|23

21P-62-K1740

BRACKET,L.H.

|23

21P-62-K1731

BRACKET,R.H.

|23

21P-62-K1730

BRACKET,R.H.

24

21K-63-54180

TUBE,L.H.

|24

21K-63-54280

TUBE,R.H.

25

21K-63-54170

TUBE,L.H.

|25

21K-63-54270

TUBE,R.H.

26

07283-22236

CLIP

27

07283-22738

CLIP

28

07372-21060

BOLT

29

01643-51032

WASHER

30

01010-81025

BOLT

31

01643-31032

WASHER

32

07372-21045

BOLT

33

01599-01011

NUT

34

07000-13030

O-RING

35

01643-50823

WASHER

36

07000-13025

O-RING

37

01010-80850

BOLT
