Запчасти Komatsu PC150-6K ОСНОВН. НАСОС (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

21P-60-K1503

PUMP ASS'Y,MAIN

|1

21P-60-K1502

PUMP ASS'Y,MAIN

|1

21P-60-K3010

PUMP ASS'Y

1

21P-60-K3040

SHAFT ASS'Y

2

21P-60-K3050

PLATE ASS'Y

3

21P-60-K3060

REGULATOR ASS'Y

|4

21P-60-K3070

ROD ASS'Y

4

21P-60-K4190

PISTON

5

21P-60-K4210

ROD

|5

21P-60-K4220

ROD

|5

21P-60-K4230

ROD

6

21P-60-K4240

SPRING

7

21P-60-K4250

BUSHING

|8

21P-60-K3080

ROD ASS'Y

8

21P-60-K4260

PISTON

9

21P-60-K4270

ROD

10

21P-60-K4280

SPRING

|11

21P-60-K3090

PLATE ASS'Y

11

21P-60-K4290

FLANGE

12

21P-60-K4310

HUB

13

21P-60-K4320

BOLT

14

21P-60-K4330

O-RING (KIT A)

15

21P-60-K4340

O-RING (KIT A)

16

21P-60-K3110

HOUSING

17

21P-60-K3120

PIN

18

21P-60-K3130

IMPELLER

19

21P-60-K3140

PIN

20

21P-60-K3150

NUT (KIT A)

21

21P-60-K3160

PLUG (KIT A)

22

21P-60-K3170

BOLT

23

21P-60-K3180

O-RING (KIT A)

24

21P-60-K3190

PLUG (KIT A)

25

21P-60-K3210

PIN

26

21P-60-K3220

RING,RETAINER

27

21P-60-K3230

SCREW

|27

20G-60-K2720

PLUG

KIT A

21P-60-K4510

SERVICE KIT,MAIN PUMP
