Запчасти Komatsu PC150-5 ГИДРОЛИНИЯ (НАВЕСНОЕ ОБОРУД-Е) ( ИЛИ ACTUATER НАВЕСН. ОБОРУД) (РУКОЯТЬ) РАБОЧЕЕ ОБОРУДОВАНИЕ

1

07099-20618

HOSE

2

07099-21018

HOSE

3

07000-13032

O-RING

4

07371-31049

FLANGE,SPLIT

5

07372-21035

BOLT

6

01643-51032

WASHER

7

21K-973-3380

TUBE

8

21K-973-3370

TUBE

9

203-62-43370

CLAMP

10

203-62-43380

CUSHION

11

203-973-5790

CLAMP

12

203-973-4390

CUSHION

13

01010-81270

BOLT

13

01010-51270

BOLT

14

01643-31232

WASHER

15

201-973-6810

NIPPLE

16

203-973-5750

NIPPLE

17

07002-13334

O-RING

18

07000-13032

O-RING

19

07371-31049

FLANGE,SPLIT

20

07372-21035

BOLT

21

01643-51032

WASHER

|$26

203-973-5803

VALVE ASS'Y

|$27

203-973-5802

VALVE ASS'Y

22

BODY

22

BODY

23

SHAFT

23

SPOOL

24

07000-13031

O-RING

24

202-973-6380

O-RING

25

202-973-6930

RING,BACK-UP

26

07000-13025

O-RING

27

07001-03025

RING,BACK-UP

28

04064-03015

RING,SNAP

29

04025-00412

PIN,SPRING

29A

203-973-6610

MAT

29B

01010-80825

BOLT

29C

01643-30823

WASHER

29D

21T-72-14930

BOSS

29D

6130-12-1961

SPACER

30

01010-81025

BOLT

30

01010-51025

BOLT

31

01643-31032

WASHER

32

203-00-56640

PLATE, MARK

33

203-973-5731

ELBOW

33

203-973-5730

ELBOW,(FOR MATSUDA)

34

07002-13334

O-RING

35

202-973-6980

PLUG

35

07042-00617

PLUG,(FOR MATSUDA)

36

07371-30640

FLANGE

37

07372-21035

BOLT

38

01643-31032

WASHER

39

07000-13025

O-RING
