Запчасти Komatsu PC150-5 МОТОР ХОДА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC150-5 - МОТОР ХОДА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33

Артикул

Название

Примечание

Количество

|1

708-8F-00033

MOTOR ASS'Y

|1

708-8F-00032

MOTOR ASS'Y

|1

708-8F-00031

MOTOR ASS'Y

|1

708-8F-04022

CASE SUB ASS'Y

|1

708-8F-04021

CASE SUB ASS'Y

1

CASE

|1

CASE

2

PLUG

3

708-8F-12111

SHAFT

4

708-8F-12151

BEARING

5

708-8F-12141

BEARING

6

706-7G-11290

SEAL,OIL

7

708-8F-12230

SPACER¤ 3.2MM

8

04065-07225

RING

9

708-8F-05010

SPACER KIT

|9

SPACER¤ 1.5MM

|9

SPACER¤ 1.6MM

|9

SPACER¤ 1.7MM

|9

SPACER¤ 1.8MM

|9

SPACER¤ 1.9MM

|9

SPACER¤ 2.0MM

|9

SPACER¤ 2.1MM

10

708-8F-13110

BLOCK,CYLINDER

11

708-8F-13211

PLATE,VALVE

12

708-8F-13520

SPRING

13

708-8F-05020

SHIM KIT

|13

SHIM¤ 0.1MM

|13

SHIM¤ 0.2MM

|13

SHIM¤ 0.5MM

14

708-8F-13510

GUIDE

15

708-8F-13340

RETAINER,SHOE

16

708-8F-13611

PISTON SUB ASS'Y

|17

708-8F-04221

CRADLE SUB ASS'Y

17

CRADLE

18

CAM,ROCKER

19

708-8F-14111

PISTON

|19

708-8F-14110

PISTON

20

708-8F-14121

PISTON

|20

708-8F-14120

PISTON

21

708-8F-14130

SPRING

22

01252-61445

BOLT

23

708-8F-13920

WASHER,SEAL

24

04020-01024

PIN

25

708-8F-15161

PISTON,BRAKE

26

07000-15170

O-RING

27

07001-05170

RING,BACK-UP

28

07000-15185

O-RING

29

07001-05185

RING,BACK-UP

30

708-8F-15150

SPRING

31

708-8F-15110

PLATE

32

708-8F-15130

PLATE

33

708-8F-15120

DISK

Выбрано товаров: 52
