Запчасти Komatsu PC150-5 МАРКИРОВКА (ЯПОН.) (ДЛЯ УДЛИНН. РЫЧАГ УПРАВЛ-Е)(№79-) МАРКИРОВКА

Схема запчастей Komatsu PC150-5 - МАРКИРОВКА (ЯПОН.) (ДЛЯ УДЛИНН. РЫЧАГ УПРАВЛ-Е)(№79-) МАРКИРОВКА
1
1
2
3
4
4
5
6
7
8
8
9
10
10
11
12
13
13
14
14
14
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
39
40
41
42
43
44
45
46

Артикул

Название

Примечание

Количество

1

21K-00-33111

PLATE¤ MARK,PC150

2

09690-C0710

PLATE¤ MARK,KOMATSU

3

09690-B0560

PLATE¤ MARK,KOMATSU

4

09690-C0315

PLATE¤ MARK,KOMATSU

5

21K-00-33140

PLATE¤ MARK,LINE

6

21K-00-33150

PLATE¤ MARK,LINE

7

203-00-51280

PLATE¤ MARK,LINE

8

20Y-00-11350

PLATE

9

20Y-00-11490

PLATE

10

20Y-00-11520

PLATE¤ MARK,AVANCE

11

201-00-61340

PLATE¤ OPERATING,LOCK

12

201-00-61380

PLATE¤ OPERATING,LOCK

13

203-00-51170

SEAT,NONSKID

14

154-54-23260

SEAT,NONSKID

15

09652-01121

PLATE¤ CAUTION,FUEL

16

201-54-21940

PLATE¤ CAUTION,HYDRAULIC TANK CAP

17

203-00-61160

PLATE¤ SAFETY

18

203-00-31120

PLATE¤ INSTRUCTION,HYDRAULIC OIL LEVEL

19

14X-98-11141

PLATE¤ SAFETY

20

09650-01104

PLATE¤ INSTRUCTION,RADIATOR

21

09667-00100

PLATE¤ SAFETY,ENGINE COVER

22

20Y-00-21121

PLATE¤ MARK

23

21K-00-33120

CHART¤ OIL

24

09637-01663

PLATE¤ INSTRUCTION

|24

09637-01661

PLATE¤ INSTRUCTION,AIR CLEANER (SINGLE ELEMENT)

25

14X-98-11380

PLATE¤ CAUTION

26

205-00-71340

PLATE¤ OPERATING,DOOR LOCK

27

09685-00002

PLATE¤ OPERATING,LOCK LEVER

28

203-00-52190

PLATE¤ CAUTION,FRONT WINDOW

29

203-00-61180

PLATE¤ CAUTION

30

203-00-52220

PLATE

31

21K-00-33132

PLATE

|31

21K-00-33131

PLATE¤ DATA

32

09602-01635

PLATE¤ NAME,(LIMITED SUPPLY)

|32

04418-13060

SCREW

33

14X-98-11161

PLATE¤ SAFETY

34

203-00-61191

PLATE¤ CAUTION

35

14X-98-11280

PLATE¤ SAFETY

36

203-00-61170

PLATE¤ CAUTION

37

203-00-61210

PLATE¤ CAUTION

38

09963-00100

TAG,(NOT SHOWN)

39

20Y-54-13473

COVER

40

20Y-54-14560

CLIP ASS'Y

41

203-916-5730

PLATE¤ OPERATING,ISO PATTERN

|41

20Y-00-11310

PLATE¤ OPERATING,KOMATSU PATTERN

|41

203-916-5130

PLATE¤ OPERATING,MITSUBISHI PATTERN

|41

203-916-5150

PLATE¤ OPERATING,SINKOU PATTERN

42

203-00-52260

PLATE¤ OPERATING,WINDOW WASHER

43

203-00-52230

PLATE¤ OPERATING,T.V.C. PROLIX

44

203-00-52240

PLATE¤ OPERATING,SWING PROLIX

45

203-916-5720

PLATE¤ OPERATING,MULTI PATTERN

46

20Y-00-22880

DECAL

Выбрано товаров: 52
