Запчасти Komatsu PC150-5 ГИДРОЛИНИЯ (P.P.C. КЛАПАН TO/FROM БЛОК) (ДЛЯ WRIST УПРАВЛ-Е)(№8-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

20Y-62-18640

HOSE¤ 720MM,(YELLOW)

2

20Y-62-18920

HOSE¤ 800MM,(WHITE)

3

20Y-62-18660

HOSE¤ 730MM,(BROWN)

4

20Y-62-18660

HOSE¤ 730MM,(BLACK)

5

20Y-62-18650

HOSE¤ 685MM,(RED)

6

20Y-62-18670

HOSE¤ 685MM,(BLUE)

7

20Y-62-18920

HOSE¤ 800MM,(WHITE)

8

20Y-62-18640

HOSE¤ 720MM,(YELLOW)

9

20Y-62-18660

HOSE¤ 730MM,(BLACK)

10

20Y-62-18660

HOSE¤ 730MM,(BROWN)

11

20Y-62-18650

HOSE¤ 685MM,(RED)

12

20Y-62-18670

HOSE¤ 685MM,(BLUE)

13

205-62-55270

NIPPLE

14

207-62-33950

NIPPLE

15

07235-10311

ELBOW

|15

207-62-33920

ELBOW

16

07002-01423

O-RING

17

20Y-62-18910

BOLT,EYE

18

07000-12018

O-RING

|18

07000-02018

O-RING

19

20Y-62-18890

BOLT,EYE

20

07000-12015

O-RING

|20

07000-02015

O-RING

21

08034-00823

BAND

22

07236-10315

ELBOW

23

07002-02034

O-RING

24

20Y-62-16221

BLOCK

25

01010-81035

BOLT

|25

01010-51035

BOLT

26

01643-51032

WASHER

27

01010-80825

BOLT

|27

01010-50825

BOLT

28

01643-30823

WASHER

29

702-16-01072

PILOT VALVE,(SEE FIG.Y1670-11A1A)

|29

702-16-01071

PILOT VALVE,(SEE FIG.Y1670-11A1A)

|29

702-16-32001

PILOT VALVE ASS'Y,(SEE FIG.Y1670-11A1)
