Запчасти Komatsu PC14R-3 СТРЕЛА (ДЛЯ ОБОРУД-Е) РАБОЧЕЕ ОБОРУДОВАНИЕ
28
25
23
22
24
27
10
6
26
5
3
2
30
3
9
1
31
10
29
15
4
16
18
14
17
12
2
19
11
3
21
20
8
31
7
30
13
7
13
1
20M-70-R2110
BOOM
2
22J-70-25142
BUSHING
3
07145-00035
SEAL, DUST
4
22L-46-12150
PLUG
5
2A1-06-15920
WORK LAMP, ASSEMBLY
6
01245-01016
SCREW
7
22J-70-16490
SPACER
8
22L-09-R8251
ELBOW
9
01640-20816
WASHER
10
22J-06-R5223
WIRING HARNESS
11
22J-70-R5151
PIN
12
07020-00000
FITTING, GREASE
13
20N-70-R1280
SPACER, 1.000 MM
14
20M-70-61120
PLATE
15
01010-81020
BOLT
16
01643-11032
WASHER
\16
22J-70-25160
PIN, ASSEMBLY
17
22J-70-25170
PIN
18
07020-00000
FITTING, GREASE
19
04082-00212
BLOCK
20
01010-81225
BOLT
21
01643-11232
WASHER
\21
22J-70-25181
PIN, ASSEMBLY
22
22J-70-25191
PIN
23
07020-00000
FITTING, GREASE
24
22L-09-R2460
PLATE
25
20N-70-R1280
SPACER, 1.000 MM
26
01010-81020
BOLT
27
01643-11032
WASHER
28
20N-70-41270
SHIM, 1.000 MM
29
22L-09-R8271
ELBOW
30
01010-80820
BOLT
31
01643-10823
WASHER
