Запчасти Komatsu PC14R-3 HS ГЕНЕРАТОР (/) ДВИГАТЕЛЬ

\0

22J-01-R5201

ENGINE, ASSEMBLY

\0

KT1K574-6401-5

ALTERNATOR, ASSEMBLY

1

KT15881-6411-0

PULLEY

2

KT15881-9201-0

NUT

3

KT15881-6415-0

COLLAR

4

KT66436-6404-0

ROTOR

5

KT15881-6480-0

COVER

6

KT16652-6477-0

BEARING, BALL

7

KT15881-6481-0

WASHER, THRUST

8

KT66436-6402-0

FRAME

9

KT15881-6471-0

PLATE

10

KT15881-9301-0

SCREW

11

KT15881-6426-0

BOLT

12

KT16652-6478-0

BEARING, BALL

13

KT16678-6406-0

FRAME

14

KT16678-6423-0

COVER

15

KT15881-6485-0

RECTIFIER, ASSEMBLY

16

KT15881-6490-0

BUSHING

17

KT16652-6431-0

HOLDER, BRUSH

18

KT15881-6409-0

BRUSH

19

KT15881-6433-0

SPRING

20

KT15881-9302-0

SCREW

21

KT15881-9303-0

SCREW

22

KT15881-9304-0

SCREW

23

KT15881-9104-0

BOLT

24

KT15881-9202-0

NUT

25

KT15881-9105-0

BOLT

26

KT14182-9203-0

NUT

27

KT1K574-6460-0

REGULATOR, ASSEMBLY
