Запчасти Komatsu PC14R-3 HS КОЛЕНВАЛ (/) ДВИГАТЕЛЬ

Схема запчастей Komatsu PC14R-3 HS - КОЛЕНВАЛ (/) ДВИГАТЕЛЬ
2
1
4
11
3
10
9
4
5
6
17
17
8
7
18
13
16
18
14
15
12
20
21
19

Артикул

Название

Примечание

Количество

\0

22J-01-R5201

ENGINE, ASSEMBLY

1

KT1G688-2111-2

PISTON

1

KT1G688-2190-2

PISTON ASSEMBLY, OS=0.25

2

KT16853-2105-0

PISTON RING, ASSEMBLY

2

KT16853-2109-0

PISTON RING ASSEMBLY, OS=0.25

3

KT16871-2131-0

PIN

4

KT15261-2133-0

CLIP

\4

KT16851-2201-5

CONNECTING ROD, ASSEMBLY

5

CONNECTING ROD

6

KT16851-2198-2

BUSHING

7

KT16851-2214-0

BOLT

8

KT16851-2232-0

METAL

8

KT15861-2297-0

METAL, US=0.20

8

KT15861-2298-0

METAL, US=0.40

8

KT1E051-2303-2

CRANKSHAFT, ASSEMBLY

9

KT16805-2301-2

CRANKSHAFT

10

KT07715-03207

BALL

11

KT19215-2328-0

SLEEVE

12

KT15841-2411-0

GEAR

13

KT05712-00515

KEY

14

KT15861-2347-0

METAL

14

KT15861-2391-0

METAL, US=0.20

14

KT15861-2392-0

METAL, US=0.40

15

KT16861-2349-0

METAL

15

KT15861-2386-0

METAL, US=0.20

15

KT15861-2387-0

METAL, US=0.40

16

KT16861-2348-0

METAL

16

KT15694-2393-0

METAL, US=0.20

16

KT15694-2394-0

METAL, US=0.40

17

KT15261-2353-0

METAL

17

KT15261-2395-0

METAL, OS=0.20

17

KT15261-2396-0

METAL, OS=0.40

18

KT15261-2354-3

METAL

18

KT15261-2397-3

METAL, OS=0.20

18

KT15261-2398-3

METAL, OS=0.40

19

KT15841-2325-0

COLLAR

20

KT15881-2331-0

SLINGER, OIL

21

KT04814-16220

O-RING

Выбрано товаров: 38
