Запчасти Komatsu PC14R-2 КАБИНА (7/8) ЧАСТИ КОРПУСА И КАБИНА

\0

22J-54-R0010

OPERATOR'S CAB, ASSY.

1

22J-54-R9160

WIPER MOTOR

2

22J-54-R9170

WIPER BLADE

3

22J-54-R8950

ARM, WIPER

4

22J-54-R9110

WIRING HARNESS

5

22J-54-R2610

BOLT

6

42N-54-19280

WASHER

7

22J-54-R8890

COVER

8

21D-54-14360

ROOM LAMP, ASSY

9

01640-20610

WASHER

10

21W-54-R2340

SCREW

11

22J-54-R9740

COAT HOOK

12

01370-40410

SCREW

13

22J-54-R9640

GLASS BREAKER

14

42N-54-17570

RIVET

15

22M-54-24950

PLATE

16

22W-54-R2350

SCREW

17

21W-54-R1940

GROMMET

18

21D-54-14420

SWITCH

19

21W-54-R2540

SWITCH

20

01583-11408

NUT

21

21W-54-R0600

STOPPER

22

22J-54-R9550

GASKET

23

22J-54-R9570

ATOMIZER, ASSY.

24

21W-54-R2310

SCREW

25

17M-911-2670

HOSE

26

21W-54-R2190

BOLT

27

01640-20408

WASHER

28

22J-54-R7581

GASKET

29

22J-54-27570

GASKET

30

22J-54-R9610

GASKET

31

22J-54-R9580

BUSHING

32

01370-00410

SCREW

33

22J-54-R8940

LEVER

34

21W-54-R2190

BOLT

35

42N-56-11960

WASHER

36

42N-56-12860

WASHER

37

42N-54-15750

PLUG
