Запчасти Komatsu PC14R-2 ПОРШЕНЬS, КОЛЕНВАЛ И РАСПРЕДВАЛ ДВИГАТЕЛЬ
№
Артикул
Название
Примечание
Количество
\0
22J-01-R5101
ENGINE, ASSY.
1
KT16851-0409-2
MAIN METAL ASSY.
2
KT15841-0454-0
BOLT
3
KT15852-0436-0
GASKET
\3
KT15841-0480-0
COVER, ASSY.
4
KT15841-0481-0
COVER
5
KT19215-9916-0
SEAL, OIL
6
KT15841-0482-2
GASKET
7
KT01023-50622
BOLT
8
KT16851-0404-0
MAIN METAL ASSY.
9
KT15841-0454-0
BOLT
10
KT16861-0405-0
MAIN METAL ASSY.
11
KT15841-0454-0
BOLT
12
KT15841-0456-2
BOLT
13
KT16851-1555-2
TAPPET
14
KT16851-1511-0
PUSH-ROD
15
KT16864-1601-0
CAMSHAFT ASSY.
16
KT07715-00401
BALL
17
KT16864-1651-0
GEAR
18
KT05712-00518
KEY
19
KT15841-1627-0
STOPPER
20
KT01023-50613
BOLT
\20
KT15875-9934-0
GEAR, ASSY.
21
KT15875-2401-3
GEAR
22
KT15875-2428-2
BUSHING
23
KT15875-2437-0
COLLAR
24
KT15875-2432-0
RING, SNAP
25
KT15875-2425-0
SHAFT
26
KT01023-50614
BOLT
27
KT1E051-2111-0
PISTON, ASSY.
27
KT1E051-2190-0
ASSY, PISTON (+0.25 mm)
28
KT16853-2105-0
PISTON RING, ASSY.
28
KT16853-2109-0
PISTON RING ASSY. (+0.25 mm)
29
KT16871-2131-0
PIN
30
KT15261-2133-0
RING, SNAP
31
KT16851-2201-5
CONNECTING ROD, ASSY.
32
KT16851-2198-2
BUSHING
33
KT16851-2214-0
BOLT
34
KT16851-2232-0
BUSHING
34
KT15861-2297-0
BUSHING (--0.20 mm)
34
KT15861-2298-0
BUSHING (--0.40 mm)
\34
KT1E051-2303-0
CRANKSHAFT, ASSY.
35
KT16805-2301-0
CRANK SHAFT
36
KT07715-03207
BALL
37
KT19215-2328-0
SLEEVE
38
KT15841-2411-0
GEAR
39
KT05712-00515
KEY
40
KT15861-2347-0
BUSHING
40
KT15861-2391-0
BUSHING (--0.20 mm)
40
KT15861-2392-0
BUSHING (--0.40 mm)
41
KT16861-2349-0
BUSHING
41
KT15861-2386-0
BUSHING (--0.20 mm)
41
KT15861-2387-0
BUSHING (--0.40 mm)
42
KT16861-2348-0
BUSHING
42
KT15694-2393-0
BUSHING (--0.20 mm)
42
KT15694-2394-0
BUSHING (--0.40 mm)
43
KT15261-2353-0
BUSHING
43
KT15261-2395-0
BUSHING (+0.20 mm)
43
KT15261-2396-0
BUSHING (+0.40 mm)
44
KT15261-2354-0
BUSHING
44
KT15261-2397-0
BUSHING (+0.20 mm)
44
KT15261-2398-0
BUSHING (+0.40 mm)
45
KT15841-2325-0
COLLAR
46
KT15881-2331-0
RING
47
KT04814-16220
O-RING
Выбрано товаров: 65
